Replacing Gateway Notebook Components www.gateway.com
28
Replacing the keyboard
Tools you need to complete this task:
Screws removed during this task:
To replace the keyboard:
1 Complete the steps in “Preparing the notebook” on page 5.
2 Remove the keyboard cover by following the instructions in “Replacing
the keyboard cover” on page 26.
Tips & Tricks
The screw hole is marked with a K.
3 Turn the notebook over so the bottom is facing up.
4 Remove the keyboard screw.
Flat-blade driver Scribe or non-marring tool- OR -
Phillips #0 screwdriver
2 black (keyboard cover)
1-3 black (keyboard)
Screw
To Next Page
