Replacing the keyboard
www.gateway.com
29
5 Loosen the six memory bay cover screws (these screws cannot be
removed).
6 Use the thumb notch to lift the memory bay cover, then remove it. Be
careful not to break off the tabs located on the end of the cover opposite
of the thumb notch.
7 Loosen the wireless bay cover screw (this screw cannot be removed), then
remove the wireless bay cover.
Screws
