Replacing Gateway Notebook Components www.gateway.com
30
Important
Depending on the keyboard features, one
or both of these screws may be absent.
8 Remove the two optional keyboard screws.
9 Turn your notebook over so the top is facing up, then open the LCD panel
to the fully opened position.
10 Lift the back edge of the keyboard slightly, then carefully push it toward
the LCD panel to release the keyboard retaining tabs. Be careful not to
damage the LCD panel.
11 Carefully rotate the keyboard toward you so it lies keys-down on top of
your notebook. Be careful not to damage the LCD panel.
Screw
Screw
To Next Page
