Replacing Gateway Notebook Components www.gateway.com
6
Disconnecting from the port replicator
To separate the notebook from the port replicator:
1 Press down on the docking release latch. The notebook will spring up
slightly.
2 Lift the notebook off of the port replicator.
Removing the batteries
Removing the main battery
To remove the main battery:
1 Turn the notebook over so the bottom is facing up.
2 Slide the battery lock to the unlock position.
