Replacing the Bluetooth module
www.gateway.com
57
6 Remove the keyboard by following the instructions in “Replacing the
keyboard” on page 28.
7 Remove the LCD panel by following the instructions in “Replacing the LCD
panel assembly” on page 35.
8 Remove the palm rest by following the instructions in “Replacing the palm
rest” on page 48.
9 Disconnect the Bluetooth cable from the system board, then slide the
Bluetooth module from the notebook.
10 Slide the new Bluetooth module into the notebook.
11 Connect the Bluetooth cable to the system board.
12 Reassemble the notebook.
