15
ENG
Connection diagram
MVR + optional GPS receiver
connection diagram
To connect the MVR with an optional GPS receiver (with a built-in
speaker), follow the connection diagram below:
Note: When connected this way, the MVR’s speaker is disabled.
Sound is transmitted via the GPS receiver’s speaker only.
Fig. 14
