Gazer F225 - Preparing Video Cameras

13
ENG
Setting up procedures
Preparing video cameras
• F225/F225g MVR comes with 2 compact video cameras for installation
on the windshield and on the back glass. Fix the video cameras in place
with 3M tape as shown in the gure below:
3M
3M
3M
3M
3M
3M
передняя
камера
задняя
камера
• Possible video camera tilt angles:
Note: When installing the video camera on a horizontal surface (in
a tilted position), use «Video rotation» function in the MVR menu to
rotate the image by 180°.
Fig. 10
Fig. 11
Front
camera
Back
camera
