ProCut 20P – Installation and Operating Instructions
There are eight functions which are as follows:
Function Name &
Rendered Drawing
Description When to Use
Behind Blade Program
01 00.00
00.00 00.00 00.00
00.00
00.00
00.0000.00
05 06
02
07
03
08
04
00
Behind blade program
Behind Blade cutting
used in program setup.
When doing large jobs with multiple cuts.
In Front Blade Program
01
00.00
00.00 00.00 00.00
00.00
00.00
00.0000.00
05 06
02
07
03
08
04
00
Front blade program
In Front Blade cutting
used in program setup
.
When doing large jobs with multiple cuts.
Unit of Measurement
01 00.00
00.00 00.00 00.00
00.00
00.00
00.0000.00
05 06
02
07
03
08
04
inch
Units
Measurements can be in
millimeters or inches
.
Use either option depending on personal preference.
Buzzer Mode
Mute
01 00.00
00.00 00.00 00.00
00.00
00.00
00.0000.00
05 06
02
07
03
08
04
x
Ability to turn on/off the
audio warning for the
Safety Curtain.
You are turning off an audible warning for a safety
feature, use at your own discretion.
Reblading Mode
Blade change mode OFF
01 00.00
00.00 00.00 00.00
00.00
00.00
00.0000.00
05 06
02
07
03
08
04
Service mode used when
replacing the blade.
CALL YOUR LOCAL SERVICE TECH OR DEALER
FOR BLADE REMOVAL OR SHARPENING
.
Reset Service adjustment to
optimize performance.
Used by the Service Technician.
Count Value
01 00.00
00.00 00.00 00.00
00.00
00.00
00.0000.00
05 06
02
07
03
08
04
000715
Total count
Provides the total cuts
performed during the
lifetime of the machine
.
After approximately 2,000 cuts the blade should be
sharpened.
Clamping Force
01 00.00
00.00 00.00 00.00
00.00
00.00
00.0000.00
05 06
02
07
03
08
04
5Press
Numeric value of
pressure applied to the
media by the Clamp.
When the paper is pulling out from under clamp during
cutting process or if too much pressure being applied
is leaving clamp marks on the media.
01 00.00
00.00 00.00 00.00
00.00
00.00
00.0000.00
05 06
02
07
03
08
04
OFF
Reset
To Next Page
