26
This generator is rated in accordance with UL (Underwriters Laboratories) 2200 (stationary engine generator assemblies) and CSA (Canadian Standards Association) standard C22.2
No. 100-4 (motors and generators).
Specifications
Generator Specifications
11k Watt
Rated Maximum Load Current* (at 25°C/77°F, LP):
at 240 Volts 45.83 Amps
Rated AC Voltage 240 Volts
Phase Single phase
Rated Frequency 60 Hertz
Normal Operating Range -20°F (-28.8°C) to 104°F
(40°C)
Output Sound Level 74 dB(A) at 23 ft. (7 m)
at full load
Shipping Weight 530 lb (241 kg)
* Natural gas rating will depend on specific fuel but typical derates are between
10 to 20% off the LP gas rating.
13k Watt
Rated Maximum Load Current* (at 25°C/77°F, LP):
at 240 Volts 54.17 Amps
Rated AC Voltage 240 Volts
Phase Single phase
Rated Frequency 60 Hertz
Normal Operating Range -20°F (-28.8°C) to 104°F
(40°C)
Output Sound Level 74 dB(A) at 23 ft. (7 m)
at full load
Shipping Weight 530 lb (241 kg)
* Natural gas rating will depend on specific fuel but typical derates are between
10 to 20% off the LP gas rating.
Engine Specifications
Displacement 49.42 ci (810 cc)
Oil Capacity 64 oz (1.9 L)
Tune-up Specifications
Spark Plug Gap 0.020 in (0.51 mm)
Armature Air Gap 0.008 - 0.012 in (0.20 - 0.30 mm)
Intake Valve Clearance 0.004 - 0.006 in (0.10 - 0.15 mm)
Exhaust Valve Clearance 0.009 - 0.011 in (0.23 - 0.28 mm)
Displacement 49.42 ci (810 cc)
Oil Capacity 64 oz (1.9 L)
Tune-up Specifications
Spark Plug Gap 0.020 in (0.51 mm)
Armature Air Gap 0.008 - 0.012 in (0.20 - 0.30 mm)
Intake Valve Clearance 0.004 - 0.006 in (0.10 - 0.15 mm)
Exhaust Valve Clearance 0.009 - 0.011 in (0.23 - 0.28 mm)
Common Service Parts
Air Filter, Oval 798748
Oil -- Synthetic 100074
Oil Filter 492932
Resistor Spark Plug 692051
Long Life Platinum Spark Plug 5066
Air Filter, Oval 798748
Oil -- Synthetic 100074
Oil Filter 492932
Resistor Spark Plug 692051
Long Life Platinum Spark Plug 5066
