9-2 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MODBUS USER MAP CHAPTER 9: USING THE MODBUS USER MAP
MODBUS User Map
Table 9-1: User Map Settings
MODBUS
Address
Hex
Addr.
Description Min Max Step Format
Code
339 Factory
Default
345 Factory
Default
350 Factory
Default
40524 20B User Map Address 1 30001 43763 1 F1 30305 Device
Status
30305 Device
Status
30305 Device
Status
40525 20C User Map Address 2 30001 43763 1 F1 30505 LED Status 30505 LED Status 30505 LED Status
40526 20D User Map Address 3 30001 43763 1 F1 30506 LED Status 30506 LED Status 30506 LED Status
40527 20E User Map Address 4 30001 43763 1 F1 30960 Trip Status 1 30960 Trip Status 1 30960 Trip Status 1
40528 20F User Map Address 5 30001 43763 1 F1 30961 Trip Status 1 30961 Trip Status 1 30961 Trip Status 1
40529 210 User Map Address 6 30001 43763 1 F1 30958 Trip Status 2 30958 Trip Status 2 30958 Trip Status 2
40530 211 User Map Address 7 30001 43763 1 F1 30959 Trip Status 2 30959 Trip Status 2 30959 Trip Status 2
40531 212 User Map Address 8 30001 43763 1 F1 30956 Trip Status 3 30956 Trip Status 3 30956 Trip Status 3
40532 213 User Map Address 9 30001 43763 1 F1 30957 Trip Status 3 30957 Trip Status 3 30957 Trip Status 3
40533 214 User Map Address 10 30001 43763 1 F1 30954 Trip Status 4 30954 Trip Status 4 30954 Trip Status 4
40534 215 User Map Address 11 30001 43763 1 F1 30955 Trip Status 4 30955 Trip Status 4 30955 Trip Status 4
40535 216 User Map Address 12 30001 43763 1 F1 30952 Alarm
Status 1
30952 Alarm
Status 1
30952 Alarm
Status 1
40536 217 User Map Address 13 30001 43763 1 F1 30953 Alarm
Status 1
30953 Alarm
Status 1
30953 Alarm
Status 1
40537 218 User Map Address 14 30001 43763 1 F1 30950 Alarm
Status 2
30950 Alarm
Status 2
30950 Alarm
Status 2
40538 219 User Map Address 15 30001 43763 1 F1 30951 Alarm
Status 2
30951 Alarm
Status 2
30951 Alarm
Status 2
40539 21A User Map Address 16 30001 43763 1 F1 30948 Alarm
Status 3
30948 Alarm
Status 3
30948 Alarm
Status 3
40540 21B User Map Address 17 30001 43763 1 F1 30949 Alarm
Status 3
30949 Alarm
Status 3
30949 Alarm
Status 3
40541 21C User Map Address 18 30001 43763 1 F1 30946 Alarm
Status 4
30946 Alarm
Status 4
30946 Alarm
Status 4
40542 21D User Map Address 19 30001 43763 1 F1 30947 Alarm
Status 4
30947 Alarm
Status 4
30947 Alarm
Status 4
40543 21E User Map Address 20 30001 43763 1 F1 30976 Cntrl
Element Status 1
30976 Cntrl
Element Status 1
30976 Cntrl
Element Status 1
40544 21F User Map Address 21 30001 43763 1 F1 30977 Cntrl
Element Status 1
30977 Cntrl
Element Status 1
30977 Cntrl
Element Status 1
40545 220 User Map Address 22 30001 43763 1 F1 30974 Cntrl
Element Status 2
30974 Cntrl
Element Status 2
30974 Cntrl
Element Status 2
40546 221 User Map Address 23 30001 43763 1 F1 30975 Cntrl
Element Status 2
30975 Cntrl
Element Status 2
30975 Cntrl
Element Status 2
40547 222 User Map Address 24 30001 43763 1 F1 30972 Cntrl
Element Status 3
30972 Cntrl
Element Status 3
30972 Cntrl
Element Status 3
40548 223 User Map Address 25 30001 43763 1 F1 30973 Cntrl
Element Status 3
30973 Cntrl
Element Status 3
30973 Cntrl
Element Status 3
40549 224 User Map Address 26 30001 43763 1 F1 30970 Cntrl
Element Status 4
30970 Cntrl
Element Status 4
30970 Cntrl
Element Status 4
40550 225 User Map Address 27 30001 43763 1 F1 30971 Cntrl
Element Status 4
30971 Cntrl
Element Status 4
30971 Cntrl
Element Status 4
40551 226 User Map Address 28 30001 43763 1 F1 30984 Block Status
1
30984 Block Status
1
30984 Block Status
1
40552 227 User Map Address 29 30001 43763 1 F1 30985 Block Status
1
30985 Block Status
1
30985 Block Status
1
