GE 350

CHAPTER 9: USING THE MODBUS USER MAP MODBUS USER MAP
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 9-3
40553 228 User Map Address 30 30001 43763 1 F1 30982 Block Status
2
30982 Block Status
2
30982 Block Status
2
40554 229 User Map Address 31 30001 43763 1 F1 30983 Block Status
2
30983 Block Status
2
30983 Block Status
2
40555 22A User Map Address 32 30001 43763 1 F1 30980 Block Status
3
30980 Block Status
3
30980 Block Status
3
40556 22B User Map Address 33 30001 43763 1 F1 30981 Block Status
3
30981 Block Status
3
30981 Block Status
3
40557 22C User Map Address 34 30001 43763 1 F1 30978 Block Status
4
30978 Block Status
4
30978 Block Status
4
40558 22D User Map Address 35 30001 43763 1 F1 30979 Block Status
4
30979 Block Status
4
30979 Block Status
4
40559 22E User Map Address 36 30001 43763 1 F1 30186 Cause of
Last Trip
30186 Cause of
Last Trip
30186 Cause of
Last Trip
40560 22F User Map Address 37 30001 43763 1 F1 30308 Time to Trip 30285 Contact
Input 1-32
30285 Contact
Input 1-32
40561 230 User Map Address 38 30001 43763 1 F1 30309 Time to Trip 30286 Contact
Input 1-32
30286 Contact
Input 1-32
40562 231 User Map Address 39 30001 43763 1 F1 30313 Time to
Reset
30298 Contact
Output 1-32
30298 Contact
Output 1-32
40563 232 User Map Address 40 30001 43763 1 F1 30307 Thermal
Capacity Used
30299 Contact
Output 1-32
30299 Contact
Output 1-32
40564 233 User Map Address 41 30001 43763 1 F1 30336 Motor Load 30288 Virtual Input
1-32
30288 Virtual Input
1-32
40565 234 User Map Address 42 30001 43763 1 F1 30285 Contact
Input 1-32
30289 Virtual Input
1-32
30289 Virtual Input
1-32
40566 235 User Map Address 43 30001 43763 1 F1 30286 Contact
Input 1-32
30317 Active
Setpoint Group
30317 Active
Setpoint Group
40567 236 User Map Address 44 30001 43763 1 F1 30298 Contact
Output 1-32
30291 Logic
Element 1-16
30291 Logic
Element 1-16
40568 237 User Map Address 45 30001 43763 1 F1 30299 Contact
Output 1-32
30296 Remote
Input 1-32
30296 Remote
Input 1-32
40569 238 User Map Address 46 30001 43763 1 F1 30288 Virtual Input
1-32
30297 Remote
Input 1-32
30297 Remote
Input 1-32
40570 239 User Map Address 47 30001 43763 1 F1 30289 Virtual Input
1-32
30300 Remote
Output 1-32
30300 Remote
Output 1-32
40571 23A User Map Address 48 30001 43763 1 F1 30290 Virtual
Output 1-32
30301 Remote
Output 1-32
30301 Remote
Output 1-32
40572 23B User Map Address 49 30001 43763 1 F1 30291 Virtual
Output 1-32
30328 W1a 30328 Ia
40573 23C User Map Address 50 30001 43763 1 F1 30296 Remote
Input 1-32
30329 W1a 30329 Ia
40574 23D User Map Address 51 30001 43763 1 F1 30297 Remote
Input 1-32
30330 W1b 30330 Ib
40575 23E User Map Address 52 30001 43763 1 F1 30300 Remote
Output 1-32
30331 W1b 30331 Ib
40576 23F User Map Address 53 30001 43763 1 F1 30301 Remote
Output 1-32
30332 W1c 30332 Ic
40577 240 User Map Address 54 30001 43763 1 F1 30192 Pre-Trip Ia 30333 W1c 30333 Ic
40578 241 User Map Address 55 30001 43763 1 F1 30193 Pre-Trip Ia 30326 W1n 30326 In
40579 242 User Map Address 56 30001 43763 1 F1 30194 Pre-Trip Ib 30327 W1n 30327 In
40580 243 User Map Address 57 30001 43763 1 F1 30195 Pre-Trip Ib 30338 W1g 30334 Iavg
40581 244 User Map Address 58 30001 43763 1 F1 30196 Pre-Trip Ic 30339 W1g 30335 Iavg
40582 245 User Map Address 59 30001 43763 1 F1 30197 Pre-Trip Ic 30324 W1sg 30338 Ig
40583 246 User Map Address 60 30001 43763 1 F1 30328 Ia 30325 W1sg 30339 Ig
MODBUS
Address
Hex
Addr.
Description Min Max Step Format
Code
339 Factory
Default
345 Factory
Default
350 Factory
Default
