GE 350

9-4 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MODBUS USER MAP CHAPTER 9: USING THE MODBUS USER MAP
40584 247 User Map Address 61 30001 43763 1 F1 30329 Ia 30319 Relay 1 Coil
Status
30324 Sense Ig
40585 248 User Map Address 62 30001 43763 1 F1 30330 Ib 30320 Relay 2 Coil
Staus
30325 Sense Ig
40586 249 User Map Address 63 30001 43763 1 F1 30331 Ib 31665 W2a 30319 Trip Coil
Status
40587 24A User Map Address 64 30001 43763 1 F1 30332 Ic 31666 W2a 30320 Close Coil
Staus
40588 24B User Map Address 65 30001 43763 1 F1 30333 Ic 31667 W2b 30001
40589 24C User Map Address 66 30001 43763 1 F1 30326 In 31668 W2b 30001
40590 24D User Map Address 67 30001 43763 1 F1 30327 In 31669 W2c 30001
40591 24E User Map Address 68 30001 43763 1 F1 30334 Iavg 31670 W2c 30001
40592 24F User Map Address 69 30001 43763 1 F1 30335 Iavg 31671 W2n 30001
40593 250 User Map Address 70 30001 43763 1 F1 30338 Ig 31672 W2n 30001
40594 251 User Map Address 71 30001 43763 1 F1 30339 Ig 31673 W2g 30001
40595 252 User Map Address 72 30001 43763 1 F1 30324 Sense Ig 31674 W2g 30001
40596 253 User Map Address 73 30001 43763 1 F1 30325 Sense Ig 31675 W2sg 30001
40597 254 User Map Address 74 30001 43763 1 F1 30319 Relay 1 Coil
Status
31675 W2sg 30001
40598 255 User Map Address 75 30001 43763 1 F1 30320 Relay 2 Coil
Status
31677 Diff Phase A 30001
40599 256 User Map Address 76 30001 43763 1 F1 30429 RTD 1 31678 Diff Phase A 30001
40600 257 User Map Address 77 30001 43763 1 F1 30430 RTD 2 31679 Diff Phase B 30001
40601 258 User Map Address 78 30001 43763 1 F1 30431 RTD 3 31680 Diff Phase B 30001
40602 259 User Map Address 79 30001 43763 1 F1 30432 RTD 4 31681 Diff Phase C 30001
40603 25A User Map Address 80 30001 43763 1 F1 30433 RTD 5 31682 Diff Phase C 30001
40604 25B User Map Address 81 30001 43763 1 F1 30434 RTD 6 31683 2nd
Harmonic Phase A
30001
40605 25C User Map Address 82 30001 43763 1 F1 30420 RTD 7 31684 2nd
Harmonic Phase B
30001
40606 25D User Map Address 83 30001 43763 1 F1 30421 RTD 8 31685 2nd
Harmonic Phase C
30001
40607 25E User Map Address 84 30001 43763 1 F1 30422 RTD 9 31686 5th
Harmonic Phase A
30001
40608 25F User Map Address 85 30001 43763 1 F1 30423 RTD 10 31687 5th
Harmonic Phase B
30001
40609 260 User Map Address 86 30001 43763 1 F1 30424 RTD 11 31688 5th
Harmonic Phase C
30001
40610 261 User Map Address 87 30001 43763 1 F1 30425 RTD 12 31695 I Restraint
Ph A
30001
40611 262 User Map Address 88 30001 43763 1 F1 30358 Vab 31696 I Restraint
Ph A
30001
40612 263 User Map Address 89 30001 43763 1 F1 30359 Vbc 31697 I Restraint
Ph B
30001
40613 264 User Map Address 90 30001 43763 1 F1 30360 Vca 31698 I Restraint
Ph B
30001
40614 265 User Map Address 91 30001 43763 1 F1 30361 Average
Line Voltage
31699 I Restraint
Ph C
30001
40615 266 User Map Address 92 30001 43763 1 F1 30366 Frequency 31700 I Restraint
Ph C
30001
40616 267 User Map Address 93 30001 43763 1 F1 30384 Power
Factor
30001 30001
40617 268 User Map Address 94 30001 43763 1 F1 30385 Real Power 30001 30001
MODBUS
Address
Hex
Addr.
Description Min Max Step Format
Code
339 Factory
Default
345 Factory
Default
350 Factory
Default
