10-4 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
339 MODBUS MEMORY MAP CHAPTER 10: 339 MODBUS MEMORY MAP AND FORMAT CODES
30431 0x1AE RTD 3 Temperature -50 251 1 °C F4 0 1
30432 0x1AF RTD 4 Temperature -50 251 1 °C F4 0 1
30433 0x1B0 RTD 5 Temperature -50 251 1 °C F4 0 1
30434 0x1B1 RTD 6 Temperature -50 251 1 °C F4 0 1
TEMPERATURE
30435 0x1B2 Ambient Temperature -50 250 1 ° F4 25 1
NEGATIVE SEQUENCE VOLTAGE ANGLE
30463 0x1CE Negative Sequence Voltage
Angle
0 359 1 °Lag F1 0 1
LEARNED DATA
30467 0x1D2 Learned Acceleration Time 0 65535 1 s F2 0 1
30468 0x1D3 Learned Starting Current 0 1200000 1 A F10 0 2
30470 0x1D5 Learned Starting Capacity 0 100 1 % F1 0 1
30471 0x1D6 Last Acceleration Time 0 65535 1 s F2 0 1
30472 0x1D7 Last Starting Current 0 1200000 1 A F10 0 2
30474 0x1D9 Last Start TCU 0 100 1 % F1 0 1
30475 0x1DA Learned Average Load 0 30000 1 x FLA F3 0 1
30476 0x1DB Learned Run Time After
Start (days)
0 65535 1 --- F1 0 1
30477 0x1DC Learned Run Time After
Start (minutes)
0 1339 1 --- F1 0 1
NEGATIVE SEQUENCE VOLTAGE METERING
30479 0x1DE Negative Sequence Voltage 0 65535 1 V F1 0 1
RTD MAXIMUMS
30485 0x1E4 RTD 1 Maximum
Temperature
-50 250 1 °C F4 0 1
30486 0x1E5 RTD 2 Maximum
Temperature
-50 250 1 °C F4 0 1
30487 0x1E6 RTD 3 Maximum
Temperature
-50 250 1 °C F4 0 1
30488 0x1E7 RTD 4 Maximum
Temperature
-50 250 1 °C F4 0 1
30489 0x1E8 RTD 5 Maximum
Temperature
-50 250 1 °C F4 0 1
30490 0x1E9 RTD 6 Maximum
Temperature
-50 250 1 °C F4 0 1
30491 0x1EA RTD 7 MAX Temp -50 250 1 °C F4 0 1
30492 0x1EB RTD 8 MAX Temp -50 250 1 °C F4 0 1
30493 0x1EC RTD 9 MAX Temp -50 250 1 °C F4 0 1
30494 0x1ED RTD 10 MAX Temp -50 250 1 °C F4 0 1
30495 0x1EE RTD 11 MAX Temp -50 250 1 °C F4 0 1
30496 0x1EF RTD 12 MAX Temp -50 250 1 °C F4 0 1
LED STATUS
30505 0x1F8 LED Status 0 0xFFFFFFFF 1 --- FC144A 0 2
USER MAP ACTUAL VALUES
30524 0x20B User Map Value 1 0 0xFFFF 1 --- F1 0 1
30525 0x20C User Map Value 2 0 0xFFFF 1 --- F1 0 1
30526 0x20D User Map Value 3 0 0xFFFF 1 --- F1 0 1
30527 0x20E User Map Value 4 0 0xFFFF 1 --- F1 0 1
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
words
