CHAPTER 10: 339 MODBUS MEMORY MAP AND FORMAT CODES 339 MODBUS MEMORY MAP
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 10-5
30528 0x20F User Map Value 5 0 0xFFFF 1 --- F1 0 1
30529 0x210 User Map Value 6 0 0xFFFF 1 --- F1 0 1
30530 0x211 User Map Value 7 0 0xFFFF 1 --- F1 0 1
30531 0x212 User Map Value 8 0 0xFFFF 1 --- F1 0 1
30532 0x213 User Map Value 9 0 0xFFFF 1 --- F1 0 1
30533 0x214 User Map Value 10 0 0xFFFF 1 --- F1 0 1
30534 0x215 User Map Value 11 0 0xFFFF 1 --- F1 0 1
30535 0x216 User Map Value 12 0 0xFFFF 1 --- F1 0 1
30536 0x217 User Map Value 13 0 0xFFFF 1 --- F1 0 1
30537 0x218 User Map Value 14 0 0xFFFF 1 --- F1 0 1
30538 0x219 User Map Value 15 0 0xFFFF 1 --- F1 0 1
30539 0x21A User Map Value 16 0 0xFFFF 1 --- F1 0 1
30540 0x21B User Map Value 17 0 0xFFFF 1 --- F1 0 1
30541 0x21C User Map Value 18 0 0xFFFF 1 --- F1 0 1
30542 0x21D User Map Value 19 0 0xFFFF 1 --- F1 0 1
30543 0x21E User Map Value 20 0 0xFFFF 1 --- F1 0 1
30544 0x21F User Map Value 21 0 0xFFFF 1 --- F1 0 1
30545 0x220 User Map Value 22 0 0xFFFF 1 --- F1 0 1
30546 0x221 User Map Value 23 0 0xFFFF 1 --- F1 0 1
30547 0x222 User Map Value 24 0 0xFFFF 1 --- F1 0 1
30548 0x223 User Map Value 25 0 0xFFFF 1 --- F1 0 1
30549 0x224 User Map Value 26 0 0xFFFF 1 --- F1 0 1
30550 0x225 User Map Value 27 0 0xFFFF 1 --- F1 0 1
30551 0x226 User Map Value 28 0 0xFFFF 1 --- F1 0 1
30552 0x227 User Map Value 29 0 0xFFFF 1 --- F1 0 1
30553 0x228 User Map Value 30 0 0xFFFF 1 --- F1 0 1
30554 0x229 User Map Value 31 0 0xFFFF 1 --- F1 0 1
30555 0x22A User Map Value 32 0 0xFFFF 1 --- F1 0 1
30556 0x22B User Map Value 33 0 0xFFFF 1 --- F1 0 1
30557 0x22C User Map Value 34 0 0xFFFF 1 --- F1 0 1
30558 0x22D User Map Value 35 0 0xFFFF 1 --- F1 0 1
30559 0x22E User Map Value 36 0 0xFFFF 1 --- F1 0 1
30560 0x22F User Map Value 37 0 0xFFFF 1 --- F1 0 1
30561 0x230 User Map Value 38 0 0xFFFF 1 --- F1 0 1
30562 0x231 User Map Value 39 0 0xFFFF 1 --- F1 0 1
30563 0x232 User Map Value 40 0 0xFFFF 1 --- F1 0 1
30564 0x233 User Map Value 41 0 0xFFFF 1 --- F1 0 1
30565 0x234 User Map Value 42 0 0xFFFF 1 --- F1 0 1
30566 0x235 User Map Value 43 0 0xFFFF 1 --- F1 0 1
30567 0x236 User Map Value 44 0 0xFFFF 1 --- F1 0 1
30568 0x237 User Map Value 45 0 0xFFFF 1 --- F1 0 1
30569 0x238 User Map Value 46 0 0xFFFF 1 --- F1 0 1
30570 0x239 User Map Value 47 0 0xFFFF 1 --- F1 0 1
30571 0x23A User Map Value 48 0 0xFFFF 1 --- F1 0 1
30572 0x23B User Map Value 49 0 0xFFFF 1 --- F1 0 1
30573 0x23C User Map Value 50 0 0xFFFF 1 --- F1 0 1
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
words
