GE 350

2-10 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
DNP PROTOCOL SETTINGS CHAPTER 2: RS485 INTERFACE
6 16-Bit Counter Change
Event with Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
23 0 Frozen Counter Event
(Variation 0 is used to
request default variation)
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
--- ---
1 32-Bit Frozen Counter Event 1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
2 16-Bit Frozen Counter Event 1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
5 32-Bit Frozen Counter Event
with Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
6 16-Bit Frozen Counter Event
with Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
30 0 Analog Input (Variation 0 is
used to request default
variation)
1 (read) 22
(assign class)
00, 01 (start-stop) 06
(no range, or all) 07,
08 (limited quantity)
17, 28 (index)
--- ---
1 32-Bit Analog Input 1 (read) 22
(assign class)
00, 01 (start-stop) 06
(no range, or all) 07,
08 (limited quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index) (see
Note 2)
2 16-Bit Analog Input 1 (read) 22
(assign class)
00, 01 (start-stop) 06
(no range, or all) 07,
08 (limited quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index) (see
Note 2)
3 32-Bit Analog Input without
Flag
1 (read) 22
(assign class)
00, 01 (start-stop) 06
(no range, or all) 07,
08 (limited quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index) (see
Note 2)
4 16-Bit Analog Input without
Flag
1 (read) 22
(assign class)
00, 01 (start-stop) 06
(no range, or all) 07,
08 (limited quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index) (see
Note 2)
32 0 Analog Change Event
(Variation 0 is used to
request default variation)
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
--- ---
1 32-Bit Analog Change Event
without Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
2 16-Bit Analog Change Event
without Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
3 32-Bit Analog Change Event
with Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
4 16-Bit Analog Change Event
with Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129 (response)
130 (unsol.
resp.)
17, 28 (index)
34 0 Analog Input Reporting
Deadband (Variation 0 is
used to request
defaultvariation)
1 (read) 00, 01 (start-stop) 06
(no range, or all) 07,
08 (limited quantity)
17, 28 (index)
--- ---
1 16-bit Analog Input
Reporting Deadband
(default - see Note 1)
1 (read) 00, 01 (start-stop) 06
(no range, or all) 07,
08 (limited quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index) (see
Note 2)
OBJECT REQUEST RESPONSE
OBJECT
NO.
VARIATION
NO.
DESCRIPTION FUNCTION
CODES (DEC)
QUALIFIER CODES
(HEX)
FUNCTION
CODES (DEC)
QUALIFIER CODES
(HEX)
