NOTE
NOTE:
1. A default variation refers to the variation response when variation 0 is requested and/
or in class 0, 1, 2, or 3 scans. The default variations for object types 1, 2, 20, 21, 22, 23,
30, and 32 are selected via relay settings. This optimizes the class 0 poll data size.
2. For static (non-change-event) objects, qualifiers 17 or 28 are only responded when a
request is sent with qualifiers 17 or 28, respectively. Otherwise, static object requests
sent with qualifiers 00, 01, 06, 07, or 08, will be responded with qualifiers 00 or 01 (for
change event objects, qualifiers 17 or 28 are always responded.)
Cold restarts are implemented the same as warm restarts – the 3 Series relay is not
restarted, but the DNP process is restarted.
2 (write) 00, 01 (start-stop)
07, 08 (limited
quantity) 17, 28
(index)
--- ---
2 32-bit Analog Input
Reporting Deadband
1 (read) 00, 01 (start-stop) 06
(no range, or all) 07,
08 (limited quantity)
17, 28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index) (see
Note 2)
2 (write) 00, 01 (start-stop)
07, 08 (limited
quantity) 17, 28
(index)
--- ---
50 1 Time and Date (default -
see Note 1)
1 (read)2 (write) 00, 01 (start-stop) 06
(no range, or all) 07
(limited qty=1) 08
(limited quantity) 17,
28 (index)
129 (response) 00, 01 (start-stop)
17, 28 (index) (see
Note 2)
60 0 Class 0, 1, 2, and 3 Data 1 (read) 20
(enable unsol) 21
(disable unsol) 22
(assign class)
06 (no range, or all) --- ---
1 Class 0 Data 1 (read) 22
(assign class)
06 (no range, or all) --- ---
2 Class 1 Data 1 (read) 20
(enable unsol)
06 (no range, or all)
07, 08 (limited
quantity)
--- ---
3 Class 2 Data 21 (disable unsol) --- ---
4 Class 3 Data 22 (assign class) --- ---
80 1 Internal Indications 1 (read) 00, 01 (start-stop)
(index =7)
129 (response) 00, 01 (start-stop)
2 (write) (see
Note 3)
00 (start-stop) (index
=7)
--- ---
No Object (function code
only) see Note 3
13 (cold restart) --- --- ---
No Object (function code
only)
14 (warm restart) --- --- ---
No Object (function code
only)
23 (delay meas.) --- --- ---
OBJECT REQUEST RESPONSE
OBJECT
NO.
VARIATION
NO.
DESCRIPTION FUNCTION
CODES (DEC)
QUALIFIER CODES
(HEX)
FUNCTION
CODES (DEC)
QUALIFIER CODES
(HEX)
