350 FORMAT CODES CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES
0xC5C2 LE 5 OP Logic Element 5 OP
0xC602 LE 6 OP Logic Element 6 OP
0xC642 LE 7 OP Logic Element 7 OP
0xC682 LE 8 OP Logic Element 8 OP
0xDC02 LE 9 OP Logic Element 9 OP
0xDC42 LE 10 OP Logic Element 10 OP
0xDC82 LE 11 OP Logic Element 11 OP
0xDCC2 LE 12 OP Logic Element 12 OP
0xDD02 LE 13 OP Logic Element 13 OP
0xDD42 LE 14 OP Logic Element 14 OP
0xDD82 LE 15 OP Logic Element 15 OP
0xDDC2 LE 16 OP Logic Element 16 OP
FC135 unsigned 16 bits Motor Speed During Trip / Motor Speed
During Event
FC136 unsigned 16 bits Motor Speed During Trip / Motor Speed
During Event
0 None None
1AA
2BB
FC139 unsigned 16 bits Starter Type
0 None None
4 Wye-Delta Wye-Delta
5 Inverter Inverter
6 Soft Starter Soft Starter
7 Custom Starter Custom Starter
FC140 unsigned 16 bits Interlock Function
0 Disabled Disabled
1TripTrip
2AlarmAlarm
FC141 unsigned 16 bits Timer Type
0 Millisecond Millisecond
1SecondSecond
2 Minute Minute
FC142 unsigned 16 bits FlexLogic Bit Field EEETTTTTTTSSSSSS
0x0000 Off Off
0x0001 On On
0x0040 Contact Inputs Contact Inputs
0x0080 Virtual Inputs Virtual Inputs
0x00C0 Virtual Outputs Virtual Outputs
0x01C0 Remote Inputs Remote Inputs
0x0380 Insert Insert
0x0400 End End
0x0440 NOT NOT
0x0480 XOR XOR
0x04C0 LATCH LATCH
0x0500 OR OR
0x0540 AND AND
Code Type Definition Long Description
