CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES 350 FORMAT CODES
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 12-187
0x0580 NOR NOR
0x05C0 NAND NAND
0x0600 TIMER TIMER
0x0640 ASSIGN ASSIGN
0x8000 Trip Trip
0x8E81 Dir Pwr 1 Trip PKP Directional Pwr 1 Trip PKP
0x8E82 Dir Pwr 1 Trip OP Directional Pwr 1 Trip OP
0x8EC1 Dir Pwr 2 Trip PKP Directional Pwr 2 Trip PKP
0x8EC2 Dir Pwr 2 Trip OP Directional Pwr 2 Trip OP
0x8FC1 Brkn Cond Trip PKP Broken Cond Trip PKP
0x8FC2 Brkn Cond Trip OP Broken Cond Trip OP
0x8FC4 Brkn Cond Trip DPO Broken Cond Trip DPO
0x9F01 WGF 1 Trip PKP Wattmetric Gnd Fault 1 Trip PKP
0x9F02 WGF 1 Trip OP Wattmetric Gnd Fault 1 Trip OP
0x9F04 WGF 1 Trip DPO Wattmetric Gnd Fault 1 Trip DPO
0x9F41 WGF 2 Trip PKP Wattmetric Gnd Fault 2 Trip PKP
0x9F42 WGF 2 Trip OP Wattmetric Gnd Fault 2 Trip OP
0x9F44 WGF 2 Trip DPO Wattmetric Gnd Fault 2 Trip DPO
0xA000 Alarm Alarm
0xAE81 Dir Pwr 1 Alrm PKP Directional Pwr 1 Alarm PKP
0xAE82 Dir Pwr 1 Alarm OP Directional Pwr 1 Alarm OP
0xAEC1 Dir Pwr 2 Alrm PKP Directional Pwr 2 Alarm PKP
0xAEC2 Dir Pwr 2 Alarm OP Directional Pwr 2 Alarm OP
0xAF01 2nd Hrmc Alarm PKP 2nd Harmonic Alarm PKP
0xAF02 2nd Hrmc Alarm OP 2nd Harmonic Alarm OP
0xAF04 2nd Hrmc Alarm DPO 2nd Harmonic Alarm DPO
0xAFC1 Brkn Cond Alrm PKP Broken Cond Alarm PKP
0xAFC2 Brkn Cond Alarm OP Broken Cond Alarm OP
0xAFC4 Brkn Cond Alrm DPO Broken Cond Alarm DPO
0xB881 CTFail Alrm PKP CT Fail Alarm PKP
0xB882 CTFail Alrm OP CT Fail Alarm OP
0xB884 CTFail Alrm DPO CT Fail Alarm DPO
0xBE02 PhDir RevAlm OP Ph Directional Reverse Alarm OP
0xBE04 PhDir RevAlm DPO Ph Directional Reverse Alarm DPO
0xBE0A PhADir RevAlm OP Ph A Directional Reverse Alarm OP
0xBE0C PhADir RevAlm DPO Ph A Directional Reverse Alarm DPO
0xBE12 PhBDir RevAlm OP Ph B Directional Reverse Alarm OP
0xBE14 PhBDir RevAlm DPO Ph B Directional Reverse Alarm DPO
0xBE22 PhCDir RevAlm OP Ph C Directional Reverse Alarm OP
0xBE24 PhCDir RevAlm DPO Ph C Directional Reverse Alarm DPO
0xBE42 PhDir UndAlm OP Ph Directional Und Alarm OP
0xBE44 PhDir UndAlm DPO Ph Directional Und Alarm DPO
0xBE4A PhADir UndAlm OP Ph A Directional Und Alarm OP
0xBE4C PhADir UndAlm DPO Ph A Directional Und Alarm DPO
0xBE52 PhBDir UndAlm OP Ph B Directional Und Alarm OP
0xBE54 PhBDir UndAlm DPO Ph B Directional Und Alarm DPO
0xBE62 PhCDir UndAlm OP Ph C Directional Und Alarm OP
Code Type Definition Long Description
