12-188 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
350 FORMAT CODES CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES
0xBE64 PhCDir UndAlm DPO Ph C Directional Und Alarm DPO
0xBE82 GndDir UndAlm OP Ground Directional Und Alarm OP
0xBE84 GndDir UndAlm DPO Ground Directional Und Alarm DPO
0xBEC2 NtrlDir UndAlm OP Neutral Directional Und Alarm OP
0xBEC4 NtrlDir UndAlm DPO Neutral Directional Und Alarm DPO
0xBF01 WGF 1 Alarm PKP Wattmetric Gnd Fault 1 Alarm PKP
0xBF02 WGF 1 Alarm OP Wattmetric Gnd Fault 1 Alarm OP
0xBF04 WGF 1 Alarm DPO Wattmetric Gnd Fault 1 Alarm DPO
0xBF41 WGF 2 Alarm PKP Wattmetric Gnd Fault 2 Alarm PKP
0xBF42 WGF 2 Alarm OP Wattmetric Gnd Fault 2 Alarm OP
0xBF44 WGF 2 Alarm DPO Wattmetric Gnd Fault 2 Alarm DPO
0xC000 Control Control
0xC302 Sync Operation Synchrocheck Operation
0xC342 Sync Close OP Synchrocheck Close OP
0xC382 Sync Condition Synchrocheck Condition
0xCE81 Dir Pwr 1 PKP Directional Pwr 1 PKP
0xCE82 Dir Pwr 1 OP Directional Pwr 1 OP
0xCEC1 Dir Pwr 2 PKP Directional Pwr 2 PKP
0xCEC2 Dir Pwr 2 OP Directional Pwr 2 OP
0xCF01 2nd Hrmc PKP 2nd Harmonic PKP
0xCF02 2nd Hrmc OP 2nd Harmonic OP
0xCF04 2nd Hrmc DPO 2nd Harmonic DPO
0xCFC1 Brkn Cond PKP Broken Cond PKP
0xCFC2 Brkn Cond OP Broken Cond OP
0xCFC4 Brkn Cond DPO Broken Cond DPO
0xD881 CTFail PKP CT Fail PKP
0xD882 CTFail OP CT Fail OP
0xD884 CTFail DPO CT Fail DPO
0xDE02 PhDir Rev OP Ph Directional Reverse OP
0xDE04 PhDir Rev DPO Ph Directional Reverse DPO
0xDE0A PhADir Rev OP Ph A Directional Reverse OP
0xDE0C PhADir Rev DPO Ph A Directional Reverse DPO
0xDE12 PhBDir Rev OP Ph B Directional Reverse OP
0xDE14 PhBDir Rev DPO Ph B Directional Reverse DPO
0xDE22 PhCDir Rev OP Ph C Directional Reverse OP
0xDE24 PhCDir Rev DPO Ph C Directional Reverse DPO
0xDE42 PhDir Und OP Ph Directional Und OP
0xDE44 PhDir Und DPO Ph Directional Und DPO
0xDE4A PhADir Und OP Ph A Directional Und OP
0xDE4C PhADir Und DPO Ph A Directional Und DPO
0xDE52 PhBDir Und OP Ph B Directional Und OP
0xDE54 PhBDir Und DPO Ph B Directional Und DPO
0xDE62 PhCDir Und OP Ph C Directional Und OP
0xDE64 PhCDir Und DPO Ph C Directional Und DPO
0xDE82 GndDir Und OP Ground Directional Und OP
0xDE84 GndDir Und DPO Ground Directional Und DPO
0xDEC2 NtrlDir Und OP Neutral Directional Und OP
Code Type Definition Long Description
