CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES 350 FORMAT CODES
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 12-189
0xDEC4 NtrlDir Und DPO Neutral Directional Und DPO
0xDF01 WGF 1 PKP Wattmetric Gnd Fault 1 PKP
0xDF02 WGF 1 OP Wattmetric Gnd Fault 1 OP
0xDF04 WGF 1 DPO Wattmetric Gnd Fault 1 DPO
0xDF41 WGF 2 PKP Wattmetric Gnd Fault 2 PKP
0xDF42 WGF 2 OP Wattmetric Gnd Fault 2 OP
0xDF44 WGF 2 DPO Wattmetric Gnd Fault 2 DPO
0xEE81 Dir Pwr 1 Blk PKP Directional Pwr 1 Block PKP
0xEE82 Dir Pwr 1 Block Directional Pwr 1 Block
0xEEC1 Dir Pwr 2 Blk PKP Directional Pwr 2 Block PKP
0xEEC2 Dir Pwr 2 Block Directional Pwr 2 Block
0xEFC1 Brkn Cond Blk PKP Broken Cond Block PKP
0xEFC2 Brkn Cond Block Broken Cond Block
0xF881 CTFail Block PKP CT Fail Block PKP
0xF882 CTFail Block CT Fail Block
0xFE02 PhDir Block Ph Directional Block
0xFE0A PhADir Block PhA Directional Block
0xFE12 PhBDir Block PhB Directional Block
0xFE22 PhCDir Block PhC Directional Block
0xFF01 WGF 1 BlockPKP Wattmetric Gnd Fault 1 Block PKP
0xFF02 WGF 1 Block Wattmetric Gnd Fault 1 Block
0xFF41 WGF 2 BlockPKP Wattmetric Gnd Fault 2 Block PKP
0xFF42 WGF 2 Block Wattmetric Gnd Fault 2 Block
FC143 unsigned 16 bits Drive Status
0 Drive Unavailable Drive Unavailable
1 Available Auto Available Auto
2 Available Manual Available Manual
3 Available Available
4 Running Running
5 ESD Trip / Stop ESD Trip / Stop
FC144 unsigned 32 bits LED Status - 350
0x00000002 In Service Green In Service Green
0x00000004 Trouble Red Trouble Red
0x00000008 Trouble Green Trouble Green
0x00000020 SP Group 1 Green SP Group 1 Green
0x00000080 SP Group 2 Green SP Group 2 Green
0x00000040 Trip Red Trip Red
0x00000400 Alarm Red Alarm Red
0x00000800 Alarm Green Alarm Green
0x00001000 Pickup Red Pickup Red
0x00002000 Pickup Green Pickup Green
0x00004000 Maintenance Red Maintenance Red
0x00008000 Maintenance Green Maintenance Green
0x00010000 BKR Open Red BKR Open Red
0x00020000 BKR Open Green BKR Open Green
0x00040000 BKR Closed Red BKR Closed Red
0x00080000 BKR Closed Green BKR Closed Green
Code Type Definition Long Description
