12-190 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
350 FORMAT CODES CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES
FC144A unsigned 32 bits LED Status - 339
FC144B unsigned 32 bits LED Status - 345
FC145 unsigned 16 bits Element Status 1
FC146 unsigned 16 bits Element Status 2
FC147 unsigned 16 bits LED Intensity
0 Level 1 Level 1
12 Level 5 Level 5
15 Level 6 Level 6
3 Level 2 Level 2
6 Level 3 Level 3
9 Level 4 Level 4
FC148 unsigned 16 bits Trigger Mode
0OverwriteOverwrite
1 Protected Protected
FC149 unsigned 16 bits OR / AND Selection
0OROR
1ANDAND
2NORNOR
3 NAND NAND
4XORXOR
5 XNOR XNOR
FC149A unsigned 16 bits AND / LATCH Selection
0ANDAND
1LATCHLATCH
FC150 unsigned 32 bits IP Address
FC155 unsigned 16 bits Profibus Baud Rate
0x0001 9600 9600
0x0002 19200 19200
0x0004 31250 31250
0x0008 45450 45450
0x0010 93750 93750
0x0020 187500 187500
0x0040 500000 500000
0x0080 1500000 1500000
0x07E2 Auto Detect Auto Detect
FC156 unsigned 16 bits DeviceNet Baud Rate
0 125 kbps 125 kbps
1 250 kbps 250 kbps
2 500 kbps 500 kbps
FC157 unsigned 16 bits LED Colour
0 Off Off
1RedRed
2GreenGreen
3 Orange Orange
FC157A unsigned 16 bits LED Colour (Subset A)
0 None None
1RedRed
Code Type Definition Long Description
