CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES 350 FORMAT CODES
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 12-191
2 Green Green
FC160 unsigned 16 bits Auto/Manual Mode
0 Auto Auto
1 Manual Manual
FC167 unsigned 32 bits Contact/Virtual Input/Output Status
FC168 unsigned 32 bits Contact/Virtual Input/Output Status
FC169 unsigned 16 bits Month
0 Not Set Not Set
1 January January
2 February February
3MarchMarch
4 April April
5MayMay
6 June June
7 July July
8 August August
9 September September
10 October October
11 November November
12 December December
FC170 unsigned 16 bits Count of Week
0 Not Set Not Set
11st1st
22nd2nd
33rd3rd
44th4th
5 Last Last
FC171 unsigned 16 bits Weekdays
0 Not Set Not Set
1SUNSUN
2MONMON
3TUETUE
4WEDWED
5THUTHU
6FRIFRI
7SATSAT
FC172 unsigned 16 bits Auto/Manual Control Stop Mode
0 Always Enabled Always Enabled
1 Follow Ctrl Mode Follow Control Mode
FC173 unsigned 16 bits Wire Selection
02W2W
13W3W
FC174 unsigned 16 bits Source Stop Action
0 Stop Stop
1TripTrip
FC175 unsigned 16 bits Test Auto/Manual Mode
0OnOn
Code Type Definition Long Description
