12-192 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
350 FORMAT CODES CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES
1 Off Off
2 Unaffected Unaffected
FC176 unsigned 16 bits Auxiliary VT Connection
0 Vab VT Vab VT
1 Vbc VT Vbc VT
2 Vca VT Vca VT
3 Van VT Van VT
4 Vbn VT Vbn VT
5Vcn VTVcn VT
6VnVn
FC177 unsigned 16 bits LED Color Invert
0 Green/Red Green/Red
1 Red/Green Red/Green
FC178 unsigned 16 bits Motor Status
FC179 unsigned 32 bits Alarm Status 1
FC180 unsigned 32 bits Alarm Status 2
FC181 unsigned 32 bits Alarm Status 3
FC182 unsigned 32 bits Alarm Status 4
FC183 unsigned 32 bits Trip Status 1
FC184 unsigned 32 bits Trip Status 2
FC185 unsigned 32 bits Trip Status 3
FC186 unsigned 32 bits Trip Status 4
FC187 unsigned 32 bits Message Status 1
FC188 unsigned 32 bits Message Status 2
FC189 unsigned 32 bits Message Status 3
FC190 unsigned 32 bits Message Status 4
FC191 unsigned 32 bits Ctrl Element Status 1
FC192 unsigned 32 bits Ctrl Element Status 2
FC193 unsigned 32 bits Ctrl Status 3
FC194 unsigned 32 bits Ctrl Status 4
FC195 unsigned 16 bits Command Status
0NormalNormal
1 Gain Forced to X1 Gain Forced to X1
FC196 unsigned 16 bits Digital Alarm
0 Active Low Active Low
1Active HighActive High
FC197 unsigned 16 bits Breaker Counter Alarm
0 Disabled Disabled
1AlarmAlarm
2 Latched Alarm Latched Alarm
3TripTrip
FC198 unsigned 16 bits Output Relay Operation
FC199 unsigned 16 bits Output Relay Type
0 Self-Reset Self-Reset
1 Latched Latched
FC200 unsigned 32 bits Block Status 1
FC201 unsigned 32 bits Block Status 2
Code Type Definition Long Description
