CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES 350 FORMAT CODES
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 12-193
FC202 unsigned 32 bits Block Status 3
FC203 unsigned 32 bits Block Status 4
FC204 unsigned 16 bits Contact Input FlexLogic Bit Field Values
0x0000 Disabled Disabled
0x0040 Contact Input 1 Contact Input 1
0x0041 Contact Input 2 Contact Input 2
0x0042 Contact Input 3 Contact Input 3
0x0043 Contact Input 4 Contact Input 4
0x0044 Contact Input 5 Contact Input 5
0x0045 Contact Input 6 Contact Input 6
0x0046 Contact Input 7 Contact Input 7
0x0047 Contact Input 8 Contact Input 8
0x0048 Contact Input 9 Contact Input 9
0x0049 Contact Input 10 Contact Input 10
FC204A unsigned 16 bits Contact Input FlexLogic Bit Field Values
(Subset A)
0x0000 Disabled Disabled
0x0040 Contact Input 1 Contact Input 1
FC204B unsigned 16 bits Contact Input FlexLogic Bit Field Values
(Subset B)
0x0000 Disabled Disabled
0x0042 Contact Input 3 Contact Input 3
0x0043 Contact Input 4 Contact Input 4
0x0044 Contact Input 5 Contact Input 5
0x0045 Contact Input 6 Contact Input 6
0x0046 Contact Input 7 Contact Input 7
0x0047 Contact Input 8 Contact Input 8
0x0048 Contact Input 9 Contact Input 9
0x0049 Contact Input 10 Contact Input 10
FC204C unsigned 16 bits Contact Input FlexLogic Bit Field Values
(Subset C)
0x0000 Disabled Disabled
0x0041 Contact Input 2 Contact Input 2
FC204D unsigned 16 bits Contact Input FlexLogic Bit Field Values
(Subset D)
0x0000 Disabled Disabled
0x0042 Contact Input 3 W2 Breaker 52a (CI#3)
FC204E unsigned 16 bits Contact Input FlexLogic Bit Field Values
(Subset E)
0x0000 Disabled Disabled
0x0044 Contact Input 5 Contact Input 5
0x0045 Contact Input 6 Contact Input 6
0x0046 Contact Input 7 Contact Input 7
0x0047 Contact Input 8 Contact Input 8
0x0048 Contact Input 9 Contact Input 9
0x0049 Contact Input 10 Contact Input 10
FC204F unsigned 16 bits Contact Input FlexLogic Bit Field Values
(Subset F)
0x0000 Disabled Disabled
Code Type Definition Long Description
