12-194 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
350 FORMAT CODES CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES
0x0043 Contact Input 4 W2 Breaker 52b (CI#4)
FC205 unsigned 16 bits Element Type 1
0 Disabled Disabled
1AlarmAlarm
2 Latched Alarm Latched Alarm
3TripTrip
4 Control Control
FC206 unsigned 16 bits Element Type 2
0 Disabled Disabled
1AlarmAlarm
2 Latched Alarm Latched Alarm
FC207 unsigned 16 bits Element Type 3
0 Disabled Disabled
1AlarmAlarm
2 Latched Alarm Latched Alarm
3 Control Control
FC208 unsigned 16 bits Relay Operation (Failsafe Non-Failsafe)
0 Failsafe Failsafe
1 Non-Failsafe Non-Failsafe
FC212 unsigned 16 bits LCD Test Paint Color
0 None None
1RedRed
2GreenGreen
3BlueBlue
FC214 unsigned 16 bits MAC Address
FC215 unsigned 32 bits GOOSE Receive Status
FC216 unsigned 16 bits Received GOOSE Message Formatting
0x0000 { {
0x0001 } }
0x0002 Bool Bool
0x0003 Byte Byte
0x0004 Ubyte Ubyte
0x0005 Short Short
0x0006 Ushort Ushort
0x0007 Long Long
0x0008 Ulong Ulong
0x0009 Int64 Int64
0x000A Uint64 Uint64
0x000B Float Float
0x000C Double Double
0x000D Btime4 Btime4
0x000E Btime6 Btime6
0x000F Utctime Utctime
0x0010 Bcd Bcd
0x0011 Vstring Vstring
0x0012 Ostring Ostring
0x0013 Ovstring Ovstring
Code Type Definition Long Description
