CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES 350 FORMAT CODES
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 12-195
0x0014 Bstring Bstring
0x0015 Bvstring Bvstring
0x00FF Row Row
FC217 unsigned 16 bits Remote Input Item Source
FC218 unsigned 16 bits Remote Input Item Mask
FC219 unsigned 32 bits GOOSE Source
0x0000 Disabled Disabled
0x0001 1 1
0x0002 2 2
0x0004 3 3
0x0008 4 4
0x0010 5 5
0x0020 6 6
0x0040 7 7
0x0080 8 8
FC220 unsigned 16 bits Remote Input Default State
0OnOn
1 Off Off
2 Latest/On Latest/On
3 Latest/Off Latest/Off
FC221 unsigned 16 bits IEC103 ASDU Identification Type
333
999
FC222 unsigned 16 bits GOOSE Type
0 Simplified Simplified
1 Advanced Advanced
FC225 unsigned 16 bits Security Audit Trail Change Method
0 Unknown Unknown
1USBUSB
2 COM1 COM1
3 Ethernet Ethernet
4 KeyPad KeyPad
FC226 unsigned 16 bits Security Audit Trail Event Type
0 Unknown Unknown
1 Setpoint Change Setpoint Change
2 Firmware File Firmware File
3 Factory Reload Factory Reload
4 Setpoint File Setpoint File
FC230 unsigned 16 bits Ethernet Connection Type
0 Copper Copper
1FiberFiber
FC235 unsigned 16 bits Switching Device
0BKRBreaker
1 Contactor Contactor
FC236 unsigned 16 bits Thermal O/L Curve
0 Standard Standard
1 Flex Curve Flex Curve
Code Type Definition Long Description
