12-196 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
350 FORMAT CODES CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES
2 Flex Curve B Flex Curve B
FC240 unsigned 16 bits Self Test Error
0 None None
1 Order Code Error Order Code Error
2 RTC Error RTC Error
4 Cal Error Cal Error
8 EEPROM Error EEPROM Error
16 System Health System Health
17 PSU Serial# Blank PSU Serial# Blank
18 INP Serial# Blank INP Serial# Blank
19 ANLG Serial# Blank ANLG Serial# Blank
20 MAG Serial# Blank MAG Serial# Blank
21 COMM Serial# Blank COMM Serial# Blank
22 CCP Serial# Blank CCP Serial# Blank
23 CPU Serial# Blank CPU Serial# Blank
24 PSU Serial# Inval PSU Serial# Invalid
25 INP Serial# Inval INP Serial# Invalid
26 ANLG Serial# Inval ANLG Serial# Invalid
27 MAG Serial# Inval MAG Serial# Invalid
28 COMM Serial# Inval COMM Serial# Invalid
29 CCP Serial# Inval CCP Serial# Invalid
30 CPU Serial# Inval CPU Serial# Invalid
32 3.3V Error 3.3V Error
64 Analog V Error Analog V Error
128 DPRAM Checksum DPRAM Checksum
256 DPRAM Heart Beat DPRAM Heart Beat
512 COMM Error COMM Error
513 DAUGHTER Error DAUGHTER Error
514 COMM HW Rev Error COMM HW Revision Error
1024 Link Error Link Error
2048 Traffic Error Traffic Error
4096 Internal Temp Internal Temp
FC401 unsigned 16 bits PC Program Reserved for FlexLogic Bit (Do
Not Use)
0 None None
FC402 unsigned 16 bits PC Program Reserved for FlexLogic Bit (Do
Not Use)
0 None None
FC403 unsigned 16 bits PC Program Reserved for FlexLogic Bit (Do
Not Use)
0 None None
FC404 unsigned 16 bits PC Program Reserved for FlexLogic Bit (Do
Not Use)
0 Off Off
1OnOn
FC405 unsigned 16 bits PC Program Reserved for FlexLogic Bit (Do
Not Use)
0 100 Ohm Pt 100 Ohm Platinum
Code Type Definition Long Description
