CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES 350 FORMAT CODES
SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 12-197
1 120 Ohm Ni 120 Ohm Nickel
2 100 Ohm Ni 100 Ohm Nickel
FC406 unsigned 16 bits PC Program Reserved for FlexLogic Bit (Do
Not Use)
0 Off Off
1OnOn
FC407 unsigned 16 bits PC Program Reserved for Output Relay
Bits (Do Not Use)
0 Disabled Disabled
333
444
555
666
777
FC408 unsigned 16 bits Inrush Function
FC409 unsigned 16 bits Inhibit Mode
0 Per Phase Per Phase
1 2-out-of-3 2-out-of-3
2 Average Average
FC410 unsigned 16 bits Overexcitation Function
FC411 unsigned 16 bits Internal Compensation
0 Internal(software) Internal(software)
1 External(with CTs) External(with CTs)
FC412 unsigned 16 bits Winding Connection
0WyeWye
1DeltaDelta
2 Zig-Zag Zig-Zag
FC413 unsigned 16 bits Grounding Connection
0 Not Within zone Not Within zone
1 Within zone Within zone
FC415 unsigned 16 bits SR345 CT Type
0 1 A Secondary 1 A Secondary
1 5 A Secondary 5 A Secondary
FC418 unsigned 16 bits CT Inputs
FC419 unsigned 16 bits XFMR Type
FC420 unsigned 16 bits Modbus File Transfer State
0IdleIdle
1WriteWrite
2ReadRead
3 File Error File Error
4 File OK File OK
5StartStart
6ReadyReady
7 File Over File Over
FC421 unsigned 16 bits Redundancy type
0 None None
1LLALLA
Code Type Definition Long Description
