GE 350

12-198 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
350 FORMAT CODES CHAPTER 12: 350 MODBUS MEMORY MAP AND FORMAT CODES
2 PRP PRP
3HSRHSR
4 DAISY CHAIN DAISY CHAIN
FC422 unsigned 16 bits Redundancy Port
0 Internal(software) Internal(software)
1 PTP PTP
3SNTPSNTP
5IRIGBIRIGB
FC423 unsigned 16 bits Redundancy State
0 Disabled Disabled
1 No Signal No Signal
2 Calibrating Calibrating
3 Synchronized Synchronized
FC424 unsigned 16 bits Dead Condition
0 None None
1 Dead Line-Dead Bus Dead Line-Dead Bus
2 Live Line-Dead Bus Live Line-Dead Bus
3 Dead Line-Live Bus Dead Line-Live Bus
4 Any Line-Dead Bus Any Line-Dead Bus
5 Dead Line-Any Bus Dead Line-Any Bus
6 One Live-Othr Dead One Live-Other Dead
7 Not Both Live Not Both Live
FC425 unsigned 16 bits Epoch type
0 UTC since 1995 UTC since 1995
1 UTC since 1900 UTC since 1900
2 UTC since 1970 UTC since 1970
3 TAI since 1970 TAI since 1970
FC426 unsigned 16 bits RSTP State
0 Discarding Discarding
1LearningLearning
2 Forwarding Forwarding
FC427 unsigned 16 bits WGF Curve Selection
0InverseInverse
4 Definite Time Definite Time
8 Flex Curve A Flex Curve A
9 Flex Curve B Flex Curve B
FC428 unsigned 16 bits Fault Recorder Type
0 TOC A TOC A
1 TOC B TOC B
2 TOC C TOC C
FC429 unsigned 16 bits Transient Sampling Rate
044
188
21616
33232
FC430 unsigned 16 bits Power Unit
0KwKw
Code Type Definition Long Description
