GE 350

3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE A–21
2.3.2 RBRF (Breaker failure)
RBRF: breaker failure (350)
RBRF: breaker failure (339/345)
2.3.3 RFLO (Fault locator)
rptRFLO: Fault report (350/339)
RBRF class
Attribute Name Attr. Type Explanation M/O/C/E Notes
RBRF_0 Breaker failure element
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M
Opln ACT_2 Operate C
RBRF class
Attribute Name Attr. Type Explanation M/O/C/E Notes
RBRF_1 Breaker failure element
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M
OpEx ACT_2 Operate C
RFLO class
Attribute Name Attr. Type Explanation M/O/C/E Notes
RFLO_0 Fault locator element
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Measured Values
FltZ CMV_2 Fault Impedance M
FltDiskm MV_2 Fault Distance in Km M
FltCause INS_5 E
FltPhases INS_5 E
