GE 350

A–22 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
rptRFLO: Fault report (345)
FltIa CMV_3 E
FltIb CMV_3 E
FltIc CMV_3 E
FltIg CMV_3 E
FltIn CMV_3 E
FltVan CMV_3 E
FltVbn CMV_3 E
FltVcn CMV_3 E
FltVab CMV_3 E
FltVbc CMV_3 E
FltVca CMV_3 E
FltVn CMV_3 E
FltVaux CMV_3 E
FltFreq MV_3 E
RFLO class
Attribute Name Attr. Type Explanation M/O/C/E Notes
RFLO_1 Fault locator element
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Measured Values
FltZ CMV_2 Fault Impedance M
FltDiskm MV_2 Fault Distance in Km M
FltCause INS_5 E
FltPhases INS_5 E
FltIa CMV_3 E
FltIb CMV_3 E
FltIc CMV_3 E
FltIg CMV_3 E
FltIn CMV_3 E
FltIa2 CMV_3 E
FltIb2 CMV_3 E
FltIc2 CMV_3 E
FltIg2 CMV_3 E
FltIn2 CMV_3 E
FltIaDiff CMV_3 E
FltIaRest CMV_3 E
FltIbDiff CMV_3 E
FltIbRest CMV_3 E
FltIcDiff CMV_3 E
FltIcRest CMV_3 E
FltFreq MV_3 E
