GGIO3: Virtual Inputs logical node.
GGIO4: Logic Elements logical node.
GGIO class
Attribute Name Attr. Type Explanation M/O/C/E Notes
GGIO_2 Generic process I/O
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Controls
SPCSO1 SPC_0 Single point controllable
status output
O
SPCSO2 SPC_0 Single point controllable
status output
O
.. .. .. ..
SPCSO32 SPC_0 Single point controllable
status output
O
Status information
Ind1 SPS_0 Virtual Input 1 O
Ind2 SPS_0 Virtual Input 2 O
.. .. .. ..
Ind32 SPS_0 Virtual Input 32 O
GGIO class
Attribute Name Attr. Type Explanation M/O/C/E Notes
GGIO_3 Generic process I/O
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Ind1 SPS_0 Logic Element 1 O
Ind2 SPS_0 Logic Element 2 O
.. .. .. ..
Ind16 SPS_0 Logic Element 16 O
