GE 350

A–26 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
GGIO5: remote inputs logical node.
rtdGGIO6: RTDs.
GGIO class
Attribute Name Attr. Type Explanation M/O/C/E Notes
GGIO_0 Generic process I/O
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status information
Ind1 SPS_0 Remote digital input 1 O
Ind2 SPS_0 Remote digital input 2 O
.. .. .. ..
Ind32 SPS_0 Remote digital input 32 O
GGIO class
Attribute Name Attr. Type Explanation M/O/C/E Notes
GGIO_4 Generic process I/O
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Measured Values
AnIn1 MV_0 RTD 1 Temp O
AnIn2 MV_0 RTD 2 Temp O
.. .. .. ..
AnIn12 MV_0 RTD 12 Temp O
Status information
Alm1 SPS_0 RTD 1 Alarm O
Alm 2 SPS_0 RTD 2 Alarm O
.. .. .. ..
Alm 12 SPS_0 RTD 12 Alarm O
Ind1 SPS_0 RTD 1 Trip O
Ind2 SPS_0 RTD 2 Trip O
.. .. .. ..
Ind12 SPS_0 RTD 12 Trip O
