20
255 Valve & Tank Adapter Module
Code Part No. Description Qty.
1 1000232 Valve Assembly, w/o Flow Controls 1
2 Camshaft: 1
1031950 Standard, One-Piece
1033024 Standard, Segmented
1033025 Extra Salt, Segmented
1033026 Long Rinse, Segmented
1032969 Water Saver, Segmented
3 1030501 Camshaft Bearing 1
4 1031391 Timer Locking Pin 1
5 1000226 Screen/Cap Assembly w/O-Ring 1
6 Drain Control Assembly w/O-Rings: 1
1000209 No. 7 (1.2 gpm; 4.5 Lpm)
1000210 No. 8 (1.6 gpm; 6.1 Lpm)
1000211 No. 9 (2.0 gpm; 7.6 Lpm)
1000212 No. 10 (2.5 gpm; 9.5 Lpm)
1000213 No. 12 (3.5 gpm; 13.2 Lpm)
1000214 No. 13 (4.1 gpm; 15.5 Lpm)**
1000215 No. 14 (4.8 gpm; 18.2 Lpm)**
7 1030502 Ball, Flow control 2
8 Brine Refill Control: 1
1034261 1 to 10 lbs Salt
1034263 3 to 19 lbs Salt
9 Injector Assembly with O-Rings: 1
1032970 “A” Injector - White
1032971 “B” Injector - Blue
1032972 “C” Injector - Red
10 1000269 Injector Cap with O-Ring 1
12 1032416 Air Check Kit 1
13 1010429 O-Ring BN 1
14 1010428 O-Ring EP 1
15 Locking Bar: 1
1031402 English Language
1031403 French Language
1031404 German Language
1031405 Italian Language
1031406 Japanese Language
1031407 Spanish Language
16 1006093 Screw, No. 8 x 9/16 inch 1
17 1001580 Spring, Valve Discs 9
18 1032565 Valve Cover, Standard, Black 1
19 1000062 i-Lid Cover 1
20 1000297 Extended Connector (For use with i-Lid Cover) 1
