March 2022
*Represents the revision number
**There will only be one baseplate raiser included with your coil. The riser is determined based on the
MR system table type.
The Wrist Array Coils replacement pads and pad kit numbers are listed in the table below. Please inspect
upon receipt to make sure all parts have arrived and are in good condition.
Description
Part number
Dunlee Order Part
number
Grey Pads
Pad Kit (includes wrist pad, base pad, finger pad,
palm pad, upper pad, elbow pad)
5406395-3
4535-303-03291
Blue Pads
8ch Wrist Coil Base Pad
5160986-7
4535-300-73141
8ch Wrist Coil Finger Pad
5160986-8
4535-300-73151
8ch Wrist Coil Palm Pad
5160986-9
4535-300-73161
8ch Wrist Coil Upper Pad
5160986-10
4535-300-73171
8ch Wrist Coil Wrist Pad
5160986-6
4535-300-73181
8ch Wrist Coil Elbow Pad
5160986-11
4535-300-73191
