Appendix B: Specifications
Note: Characteristics are subject to change without prior notice.
Rack Model # UPS0600ITSIR UPS1000ITSIR UPS1500ITSIR UPS2000ITSIR
Tower Model # UPS0600ITSIT UPS1000ITSIT UPS1500ITSIT UPS2000ITSIT
Topology Line Interactive
Output VA/Watts 600VA/360W 1000VA/600W 1500VA/900W 2000VA/1200W
Output Power Factor 0.6
Output voltage (Battery Mode) 120V, Pure sine wave at +/-5% of nominal, -10% of nominal after low battery warning
Output Voltage (Utility Mode) 120V, +/-10%
Output Frequency 50/60 Hz +/- 0.5% (Auto sensing: default 60Hz or follows latest I/P frequency)
AVR Boost/Trim Boost 17%, Buck 14%
Output voltage THD <5%, @ 100% resistive load with 80% battery capacity
Input voltage at full load 120V, +/-10%
Input current at nominal voltage 6 max. 10 max. 15 max. 20 max.
Input – Buck / Comeback 128/131, +/- 3V
Input – Boost / Comeback 109/112, +/- 3V
Low line loss / comeback 90/95, +/- 3V
High line loss / comeback 150/145, +/- 3V
Input Frequency (Hz) 50 or 60 Hz +/-5Hz (Auto sensing)
UPS efficiency On Battery: >80% with 100% resister load. On Utility: >95% @ full charged battery & 100% Resistive load
Voltage Drop in Transformer in
Utility mode @ 100% load
< 2V
Acoustic noise (dBA) <40dBA (1 meter from surface) <45dBA (1 meter from surface)
Ambient temperature ⁰F (⁰C) 3,500 meters max. elevation, 32-95 ⁰F (0-35 ⁰C)
Humidity 0-95% humidity non-condensing,
# of Outlets (NEMA 5-15R) Tower: 4, Rack Mount: 4 Tower: 4, Rack Mount: 4 Tower: 6, Rack Mount: 4 Tower: 6, Rack Mount: 6
Input line 6Ft, Cord NEMA 5-15P NEMA 5-20P
Enclosure Specifications for Rack
Mount Models
Compatible with 19” Rack
Fan speed Tower: Temperature and Load dependent, Rack Mount: Constant
Front display LED
Audio Alarm: Battery mode: Slow beeping sound (about 0.25Hz)
Battery low/charger fault: Rapid beeping sound (about 1Hz)
UPS fault: Continue beeping sound
Overload: Continue beeping sound
Sleep mode Dual rapid beeping sound every 5 sec.
Alarm silence: by push-on button for 1 second
UPS parameters user configurable Software Via RS-232
Battery replacement procedure Hot swappable
Battery type 34W, Maintenance free sealed Lead Acid battery with 2 to 4 years typical lifetime
Battery capacity (12V /34W) x 2 (12V/34W) x 2 (12V/34W) x 3 (12V/34W) x 4
Back-up time @ full load 10 mins 4-5 mins 4-5 mins 4-5 mins
Recharge time to 90% cap 4 hours
Charging Current 1.5A
Min. Battery Start up Voltage 16 16 24 32
Transfer time. Typical 4~6 ms.
Input protection Breaker
Surge capability, peak current
capability
6500A/780 Joule
Communication USB and RS232 (One port works at a time)
Overload Protection UPS automatic shutdown if overload exceeds 110% nominal at 20 sec and 125% at 5 sec
Short circuit protection Yes
SNMP Card Slot SNMP slot provision. Must be integrated in the UPS
