BINARY INPUT / BINARY INPUT CHANGE CHAPTER 6: DNP POINT LISTS
1. Any detected change in the state of any point will cause the generation of an event
object.
2. An event object will be generated as a result of any change in any point.
15 Diagnostic Message(s) Active Class 1
16 Major Internal Failure Class 1
17 Minor Internal Failure Class 1
18 Testing Mode Active Class 1
19 Contact Input 1 Closed Class 1
20 Contact Input 2 Closed Class 1
21 Contact Input 3 Closed Class 1
22 Contact Input 4 Closed Class 1
23 Contact Input 5 Closed Class 1
24 Contact Input 6 Closed Class 1
25 Contact Input 7 Closed Class 1
26 Contact Input 8 Closed Class 1
27 Contact Input 9 Closed Class 1
28 Contact Input 10 Closed Class 1
29 Contact Input 11 Closed Class 1
30 Contact Input 12 Closed Class 1
31 Contact Input 13 Closed Class 1
32 Contact Input 14 Closed Class 1
33
Setpoint Access Jumper
Present
Class 1
34 Coil Monitor 1 Circuit Closed Class 1
35 Coil Monitor 2 Circuit Closed Class 1
36 Relay 1 Trip Operated Class 1
37 Relay 2 Close Operated Class 1
38 Relay 3 Auxiliary Operated Class 1
39 Relay 4 Auxiliary Operated Class 1
40 Relay 5 Auxiliary Operated Class 1
41 Relay 6 Auxiliary Operated Class 1
42 Relay 7 Auxiliary Operated Class 1
43 Relay 8 Service Operated Class 1
Table 1: Binary Inputs DNP Points
Index Description Event
Class
