CHAPTER 6: DNP POINT LISTS ANALOG INPUT / ANALOG INPUT CHANGE
750/760 FEEDER MANAGEMENT RELAY – COMMUNICATIONS GUIDE 6 - 5
Analog Input / Analog Input Change
In the following table, the entry in the “Format” column indicates that the format of the
associated data point can be determined by looking up the entry in the Memory Map Data
Formats table. For example, an “F1” format is described in that table as a (16-bit) unsigned
value without any decimal places. Therefore, the value read should be interpreted in this
manner.
The point list for Analog Input (Object 30) and Analog Input Change (Object 32) is shown
below. Refer to the notes following the table for additional details.
Table 3: Analog Inputs DNP Points (Sheet 1 of 8)
Index when Point
Mapping is:
Format Description Event
Class
Assigned
Disable
d
Enabled
n/a 0 - User Map Value 1
n/a 1 - User Map Value 2
↓↓↓↓
n/a 118 - User Map Value 119
n/a 119 - User Map Value 120
0 120 F49 Phase Time Overcurrent 1 Class 1
1 121 F49 Phase Instantaneous Overcurrent 1 Class 1
2 122 F49 Phase Instantaneous Overcurrent 2 Class 1
3 123 F49 Ground Time Overcurrent Class 1
4 124 F49 Ground Instantaneous Overcurrent Class 1
5 125 F49 Neutral Time Overcurrent 1 Class 1
6 126 F49 Neutral Time Overcurrent 2 Class 1
7 127 F49 Neutral Instantaneous Overcurrent 1 Class 1
8 128 F49 Neutral Instantaneous Overcurrent 2 Class 1
9 129 F49 Phase Directional Is Reverse Class 1
10 130 F49 Neutral Directional Is Reverse Class 1
11 131 F49 Manual Close Blocking Class 1
12 132 F49 Cold Load Pickup Blocking Class 1
13 133 F49 Bus Undervoltage 1 Class 1
14 134 F49 Bus Undervoltage 2 Class 1
15 135 F49 Line Undervoltage 1 Class 1
