GE 8 Series User Manual

Modifications reserved Page 30/99
OPM_SPE_XXX_10K_40K_8GB_V020.doc Operating Manual SitePro 10-15-20-30-40 kVA / S8
Separate input Rectifier & Bypass Common input Rectifier & Bypass
Fig. 5.7.2-1 Separate input rectifier & bypass Fig. 5.7.2-2 Common input rectifier & bypass
1 = Rectifier
2 = Inverter
3 = Automatic bypass
4 = Manual bypass
5 = Mains input
6 = Load
7 = Battery
Fuses AgL / Circuit breakers (3x380/220V, 3x400/230V, 3x415/240V)
UPS Model F1 F2 F3 (= F1) F4
SitePro 10 kVA 3 x 25 A 3 x 20 A 3 x 25 A 2 x 40 A
SitePro 15 kVA 3 x 40 A 3 x 25 A 3 x 40 A 2 x 63 A
SitePro 20 kVA 3 x 50 A 3 x 35 A 3 x 50 A 2 x 63 A
SitePro 30 kVA 3 x 63 A 3 x 50 A 3 x 63 A 2 x 100 A
SitePro 40 kVA 3 x 80 A 3 x 63 A 3 x 80 A 2 x 100 A
Cables section (mm
2
) A, B, C, D, E, K / Recommended by European Standards (EN)
UPS Model A B C + E D K
SitePro 10 kVA 4 x 4 mm
2
4 x 2,5 mm
2
5 x 4 mm
2
5 x 2,5 mm
2
3 x 6 mm
2
SitePro 15 kVA 4 x 6 mm
2
4 x 4 mm
2
5 x 6 mm
2
5 x 4 mm
2
3 x 10 mm
2
SitePro 20 kVA 4 x 10 mm
2
4 x 6 mm
2
5 x 10 mm
2
5 x 6 mm
2
3 x 10 mm
2
SitePro 30 kVA 4 x 10 mm
2
4 x 10 mm
2
5 x 10 mm
2
5 x 10 mm
2
2x25 + 1x16 mm
2
SitePro 40 kVA 4 x 16 mm
2
4 x 10 mm
2
5 x 16 mm
2
5 x 10 mm
2
2x25 + 1x16 mm
2
Cables section (mm
2
) A, B, C, D, E, K / Recommended in Switzerland
UPS Model A B C + E D K
SitePro 10 kVA 4 x 6 mm
2
4 x 4 mm
2
5 x 6 mm
2
5 x 4 mm
2
3 x 10 mm
2
SitePro 15 kVA 4 x 10 mm
2
4 x 6 mm
2
5 x 10 mm
2
5 x 6 mm
2
3 x 16 mm
2
SitePro 20 kVA 4 x 16 mm
2
4 x 10 mm
2
5 x 16v 5 x 10 mm
2
3 x 16 mm
2
SitePro 30 kVA 4 x 16 mm
2
4 x 16 mm
2
5 x 16 mm
2
5 x 16 mm
2
2x35 + 1x25 mm
2
SitePro 40 kVA 3x25 + 1x16 mm
2
4 x 16 mm
2
4x25 + 1x16 mm
2
5 x 16 mm
2
2x35 + 1x25 mm
2
NOTE !
The delivery and installation of fuses and input/output connections of the UPS are at
the customer’s expense, unless agreed otherwise.
