CHAPTER 11: MODBUS MEMORY MAP MODBUS MEMORY MAP
869 MOTOR PROTECTION SYSTEM – COMMUNICATIONS GUIDE 11-7
30621 0x026C User Map Value 98 0 65535 1 F0 0 1
30622 0x026D User Map Value 99 0 65535 1 F0 0 1
30623 0x026E User Map Value 100 0 65535 1 F0 0 1
30624 0x026F User Map Value 101 0 65535 1 F0 0 1
30625 0x0270 User Map Value 102 0 65535 1 F0 0 1
30626 0x0271 User Map Value 103 0 65535 1 F0 0 1
30627 0x0272 User Map Value 104 0 65535 1 F0 0 1
30628 0x0273 User Map Value 105 0 65535 1 F0 0 1
30629 0x0274 User Map Value 106 0 65535 1 F0 0 1
30630 0x0275 User Map Value 107 0 65535 1 F0 0 1
30631 0x0276 User Map Value 108 0 65535 1 F0 0 1
30632 0x0277 User Map Value 109 0 65535 1 F0 0 1
30633 0x0278 User Map Value 110 0 65535 1 F0 0 1
30634 0x0279 User Map Value 111 0 65535 1 F0 0 1
30635 0x027A User Map Value 112 0 65535 1 F0 0 1
30636 0x027B User Map Value 113 0 65535 1 F0 0 1
30637 0x027C User Map Value 114 0 65535 1 F0 0 1
30638 0x027D User Map Value 115 0 65535 1 F0 0 1
30639 0x027E User Map Value 116 0 65535 1 F0 0 1
30640 0x027F User Map Value 117 0 65535 1 F0 0 1
30641 0x0280 User Map Value 118 0 65535 1 F0 0 1
30642 0x0281 User Map Value 119 0 65535 1 F0 0 1
30643 0x0282 User Map Value 120 0 65535 1 F0 0 1
30644 0x0283 User Map Value 121 0 65535 1 F0 0 1
30645 0x0284 User Map Value 122 0 65535 1 F0 0 1
30646 0x0285 User Map Value 123 0 65535 1 F0 0 1
30647 0x0286 User Map Value 124 0 65535 1 F0 0 1
30648 0x0287 User Map Value 125 0 65535 1 F0 0 1
Event Recorder
30660 0x0293 Date/Time Of Last Clear 0 0xFFFFFFFF 1 F50 0 1
30662 0x0295 Time Of Last Clear (us) 0 999999 1 us F51 0 1
30664 0x0297 Events Since Last Clear 0 1024 1 F10 0 1
Input / Output Status
30700 0x02BB CI Inputs 1-32 0 0xFFFFFFFF 1 FC194 0 1
30706 0x02C1 CO Outputs 0 0xFFFFFFFF 1 FC198 0 1
30708 0x02C3 LED 1-32 0 0xFFFFFFFF 1 F10 0 1
30712 0x02C7 Device Status 0 0xFFFFFFFF 1 FC135 0 1
30714 0x02C9 Virtual Inputs 1-32 0 0xFFFFFFFF 1 F10 0 1
30718 0x02CD Virtual Inputs 65-96 0 0xFFFFFFFF 1 F10 0 1
30720 0x02CF Virtual Inputs 97-128 0 0xFFFFFFFF 1 F10 0 1
30722 0x02D1 Virtual Outputs 1-32 0 0xFFFFFFFF 1 F10 0 1
30728 0x02D7 Virtual Outputs 97-128 0 0xFFFFFFFF 1 F10 0 1
30734 0x02DD Remote Inputs 1-32 0 0xFFFFFFFF 1 FC191 0 1
30746 0x02E9 Element Status 1 (Any
Trip)
0 65535 1 FC151 0 1
30747 0x02EA Element Status 2 (Any
Alarm)
0 65535 1 FC151 0 1
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
