GE 869 - Selection of Standard Information Numbers in Control Direction

CHAPTER 7: IEC 60870-5-103 INTEROPERABILITY
869 MOTOR PROTECTION SYSTEM – COMMUNICATIONS GUIDE 7-7
Table 7-9: Measurands in monitor direction
Table 7-10: Generic functions in monitor direction
Selection of standard
information numbers
in control direction
Table 7-11: System functions in control direction
Table 7-12: General commands in control direction
Table 7-13: General functions in control direction
INF Semantics 869 Identifier 869 Data Text
□ <144> Measurand I
□ <145> Measurands I, V
□ <146> Measurands I, V, P, Q
□ <147> Measurands In, Ven
□ <148> Measurands IL123, VL123, P, Q, f
INF Semantics
□ <240> Read headings of all defined groups
□ <241> Read values or attributes of all entries of one group
□ <243> Read directory of a single entry
□ <244> Read value or attribute of a single entry
□ <245> End of general interrogation of generic data
□ <249> Write entry with confirmation
□ <250> Write entry with execution
□ <251> Write entry aborted
INF Semantics
⊠ <0> Initiation of general interrogation
⊠ <0> Time synchronization
INF Semantics
□ <16> Auto-recloser on / off
□ <17> Teleprotection on / off
□ <18> Protection on / off
□ <19> LED reset
□ <23> Activate characteristic 1
□ <24> Activate characteristic 2
□ <25> Activate characteristic 3
□ <26> Activate characteristic 4
INF Semantics
□ <240> Read headings of all defined groups
□ <241> Read values or attributes of all entries of one group
□ <243> Read directory of a single entry
□ <244> Read value or attribute of a single entry
□ <245> General interrogation of generic data
□ <248> Write entry
□ <249> Write entry with confirmation
□ <250> Write entry with execution
□ <251> Write entry abort
