CHAPTER 11: MODBUS MEMORY MAP MODBUS MEMORY MAP
869 MOTOR PROTECTION SYSTEM – COMMUNICATIONS GUIDE 11-9
30784 0x030F Element Status 39 (BKR2
52a Contact)
0 65535 1 FC151 0 1
30788 0x0313 Element Status 43 (BKR3
Status Unknown)
0 65535 1 FC151 0 1
30789 0x0314 Element Status 44 (BKR3
Status Disconnected)
0 65535 1 FC151 0 1
30790 0x0315 Element Status 45 (BKR3
52a Contact)
0 65535 1 FC151 0 1
30791 0x0316 Element Status 46 (BKR3
52b Contact)
0 65535 1 FC151 0 1
30792 0x0317 Element Status 47
(Contactor Status Closed)
0 65535 1 FC151 0 1
30793 0x0318 Element Status 48
(Contactor Status
Opened)
0 65535 1 FC151 0 1
30794 0x0319 Element Status 49
(Contactor Status
Unknown)
0 65535 1 FC151 0 1
30797 0x031C Element Status 52 (Start) 0 65535 1 FC151 0 1
30799 0x031E Element Status 54
(Contactor2 Status
Opened)
0 65535 1 FC151 0 1
30801 0x0320 Element Status 56
(Contactor2 Status
Disconnected)
0 65535 1 FC151 0 1
30802 0x0321 Element Status 57 (Stop
2)
0 65535 1 FC151 0 1
30803 0x0322 Element Status 58 (Start
2)
0 65535 1 FC151 0 1
30804 0x0323 Element Status 59
(Contactor3 Status
Closed)
0 65535 1 FC151 0 1
30805 0x0324 Element Status 60
(Contactor3 Status
Opened)
0 65535 1 FC151 0 1
30806 0x0325 Element Status 61
(Contactor3 Status
Unknown)
0 65535 1 FC151 0 1
30807 0x0326 Element Status 62
(Contactor3 Status
Disconnected)
0 65535 1 FC151 0 1
30808 0x0327 Element Status 63 (Stop
3)
0 65535 1 FC151 0 1
30809 0x0328 Element Status 64 (Start
3)
0 65535 1 FC151 0 1
30810 0x0329 Element Status 65 (VFD) 0 65535 1 FC151 0 1
30811 0x032A Element Status 66
(Percent Diff 1)
0 65535 1 FC151 0 1
30812 0x032B Element Status 67
(Percent Diff 2)
0 65535 1 FC151 0 1
30813 0x032C Element Status 68
(Percent Diff 1 Saturation)
0 65535 1 FC151 0 1
30815 0x032E Element Status 70
(Percent Diff 1 Direction)
0 65535 1 FC151 0 1
30817 0x0330 Element Status 72
(Percent Diff 1 Warning)
0 65535 1 FC151 0 1
30818 0x0331 Element Status 73
(Percent Diff 2 Warning)
0 65535 1 FC151 0 1
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
