11-4 869 MOTOR PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 11: MODBUS MEMORY MAP
30005 0x0004 Boot 0 65535 1 F2 0 1
30006 0x0005 Firmware Date 0x010107D8 0x0C1F082E 1 F53 16844760 1
30008 0x0007 Firmware Time 0 0x173B3B63 1 F54 0 1
30010 0x0009 Boot Date 0x010107D8 0x0C1F082E 1 F53 16844760 1
30012 0x000B Boot Time 0 0x173B3B63 1 F54 0 1
30014 0x000D Product Serial # 0 65535 1 F60_12 Serial 12
30021 0x0014 Order Code 0 65535 1 F60_34 OrderCode 34
30038 0x0025 MAC Address 1 0 65535 1 F60_6A 0 6
30047 0x002E Comms CPU fw Version 0 65535 1 F2 0 1
30049 0x0030 Boot 0 65535 1 F2 0 1
30050 0x0031 Comms CPU Firmware
Date
0x010107D8 0x0C1F082E 1 F53 16844760 1
30052 0x0033 Comms CPU Firmware
Time
0 0x173B3B63 1 F54 0 1
30054 0x0035 Boot Date 0x010107D8 0x0C1F082E 1 F53 16844760 1
30056 0x0037 Boot Time 0 0x173B3B63 1 F54 0 1
30058 0x0039 MAC Address 1 0 65535 1 F60_6A 0 6
30061 0x003C MAC Address 2 0 65535 1 F60_6A 0 6
30067 0x0042 FPGA Firmware Version 0 0xFFFFFFFF 1 F71 0 1
30069 0x0044 IO F CPLD 0 0xFFFFFFFF 1 F71 0 1
30071 0x0046 IO G CPLD 0 0xFFFFFFFF 1 F71 0 1
30075 0x004A AN J CPLD 0 0xFFFFFFFF 1 F71 0 1
30077 0x004C AN K CPLD 0 0xFFFFFFFF 1 F71 0 1
30079 0x004E Display CPLD 0 0xFFFFFFFF 1 F71 0 1
Time
30241 0x00F0 Time 0 0x173B3B63 1 F54 0 1
30243 0x00F2 Date 0x010107D8 0x0C1F082E 1 F53 16844760 1
30245 0x00F4 RTC Time 0 0xFFFFFFFF 1 s F52 0 1
30247 0x00F6 System Clock 0 0xFFFFFFFF 1 s F52 0 1
Targets
30257 0x0100 Target Custom Text 0 65535 1 F60_26 26
30270 0x010D Target Count 0 256 1 F0 0 1
30271 0x010E Target Cause 0 0xFFFFFFFF 1 FC134 0 1
30273 0x0110 Target Type 0 2 1 FC101 0 1
30274 0x0111 Target Time 0 60000 1 F0 0 1
PTP Status
30300 0x012B RTC Sync Source 0 4 1 FC342 0 1
30301 0x012C Grandmaster ID 0 65535 1 F60_8A 0 8
30305 0x0130 RTC Accuracy -999999999 999999999 1 ns F30 0 1
30307 0x0132 Port 4 PTP State 0 4 1 FC343 1 1
30308 0x0133 Port 5 PTP State 0 4 1 FC343 1 1
User Map Values
30524 0x020B User Map Value 1 0 65535 1 F0 0 1
30525 0x020C User Map Value 2 0 65535 1 F0 0 1
30526 0x020D User Map Value 3 0 65535 1 F0 0 1
30527 0x020E User Map Value 4 0 65535 1 F0 0 1
30528 0x020F User Map Value 5 0 65535 1 F0 0 1
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
