ADTS552F
K0553 Revision D
8
[EN] English
ADTS552F
The ADTS552F incorporates all
the features of the ADTS542F bu
t with an optional communica-
tions board, which is located below the cover (10).
Figure 1-2: ADTS552F General Arrangement
10
Cover for
,
optional, communications boar
