Power Supply Connection
The unit must be connected to the correct electrical power supply as stated, adjacent to the
power connector.
A qualified technician (see page i) must carry out the following procedure.
A power isolation device must be accessible at all times. This device can be considered as
disconnecting the ADTS power cable or building wall isolation switch. The ADTS front panel
switch is not classed as a power isolator.
CAUTION
THE SUPPLY MUST PROVIDE CONNECTION TO A PROTECTIVE GROUND TERMINAL. THE UNIT
MUST, AT ALL TIMES, BE CONNECTED TO THE SUPPLY EARTH (GROUND).
THE POWER SUPPLY CABLE AND CONNECTOR MUST BE CORRECTLY RATED FOR THE POWER
SUPPLY.
Fuses
The two fuses, located in the holders and mounted on the front panel, protect the unit. The fuses
are connected in the live and neutral supply circuit and are rated at:
- T5AH 250V 20mm
External functional earth/ground terminal
An external earth/ground connection stud is available as functional earth on the front panel
providing a connection point for other equipment to be connected to the same earth/ground
connection as the test set (This is not a protective earth/ground connection).
European Colour US Color Function
Brown Black Live
Blue White Neutral
Green/Yellow Green Protective Earth (Ground)
