DASHBOARD

[EN] English 39 K0553 Revision D

Figure 3-4: Test Sequence

1 Pitot static 2 EPR see section Engine

Pressure Ratio (EPR)

3 Settings 4 Tools

5 Test sequence (swipe

horizontally to view) (see

section Test sequence)
