Table – 1 (208V)
Device
AF - 600 HP Rating(s)
Minimum Wire Size
Maximum Wire Size
Required Torque
NON FUSED DISCONNECTOR
AND FUSE BLOCK
2-5Hp
# 14 AWG
# 4 AWG
Note 1
7.5-10HP
# 14 AWG
# 4 AWG
Note 1
15-20
# 8 AWG
1/0
Note 1
25-30
# 8 AWG
1/0
Note 1
40-60
# 4 AWG
300 MCM
Note 1
FUSED DISCONNECTOR
1 through 15
# 10 AWG
# 3 AWG
Note 1
20
# 14 AWG
# 2/0 AWG
Note 1
25 through 50
# 6 AWG
# 3/0 AWG
Note 1
60
# 2 AWG
600MCM
Note 1
Circuit Breaker
1 through 30
# 12 AWG
# 3/0 AWG
Note 1
40 through 60
# 8 AWG
350 MCM
Note 1
Overload Relay
1 through 10
# 14 AWG
# 8 AWG
20 lb. in.
15 through 30
# 10 AWG
# 3 AWG
50 lb. in.
40 through 50
# 6 AWG
250 MCM
275 lb. in., Note 2
60
# 6 AWG
350 MCM
200 lb. in., Note 2
Drive output power Terminal
Board
1 through 5
# 4 AWG
# 10 AWG
16 lb.in.
7.5 through 15
# 10 AWG
# 7 AWG
16 lb.in.
20
# 35 AWG
# 2 AWG
40 lb.in.
25 through 40
# 50 AWG
1/0
89 lb.in.
50
# 95 AWG
4/0
212 lb.in.
60
# 120 MCM
250MCM
212 lb.in.
Load Reactor (6KFP Series)
1 through 2
# 22 AWG
# 10 AWG
4.5 lb.in
3 through 10
# 14 AWG
# 6 AWG
16 lb.in
15 through 30
# 6 AWG
1/0
45 lb.in (6 - 4AWG),
50 lb.in (2-1/0 AWG)
40
# 2 AWG
4/0
150 lb.in
50 through 60
Note 2
Note 2
Note 1
Load Reactor (6KFP*L
Series) - 3% Z
1 through 3
# 22 AWG
# 10 AWG
4.5 lb.in
5
# 14 AWG
# 6 AWG
16 lb.in
7.5
# 22 AWG
# 14 AWG
16 lb.in
10
# 14 AWG
# 6 AWG
16 lb.in
15 through 25
# 6 AWG
1/0
45 lb.in (6 - 4AWG),
50 lb.in (2-1/0 AWG)
30 through 60
Note 2
Note 2
Note 1
Control Terminal Board
1 through 60
# 26 AWG
# 10 AWG
Note 1
Note (1): For unmentioned torques, Refer UL508A tables in tab "UL508A" in the same excel file
Note (2): The input and output terminals have Busbars provision for motor connections.
