Table – 2 (460V)
Device
AF - 600 HP
Rating(s)
Minimum Wire Size
Maximum Wire Size
Required Torque
NON FUSED
DISCONNECTOR AND FUSE
BLOCK
1 through 10Hp
# 14 AWG
# 4 AWG
Note 1
15 through 30Hp
# 14 AWG
# 4 AWG
Note 1
40 through 50Hp
# 8 AWG
1/0
Note 1
60 through 75Hp
# 8 AWG
1/0
Note 1
100 through 125Hp
# 4 AWG
300 MCM
Note 1
150 through 300Hp
# 2 AWG
600 MCM
Note 1
FUSED DISCONNECTOR
1 through 30
# 10 AWG
# 3 AWG
Note 1
40 through 50
# 14 AWG
# 2/0 AWG
Note 1
60 through 100
# 6 AWG
# 3/0 AWG
Note 1
125 through 250
# 2 AWG
# 600MCM
Note 1
300 through 500
2 X # 2 AWG
2 X 600MCM
Note 1
550 through 600
4 X # 2 AWG
4 X 600MCM
Note 1
Circuit Breaker
1 through 75
# 12 AWG
# 3/0 AWG
Note 1
100 through 150
# 8 AWG
350 MCM
Note 1
200 through 350
2 X 2/0
2 X 500 MCM
Note 1
200 through 350
#8 AWG
600 MCM
Note 1
450 through 500
3X #3/0 AWG
3X 500 MCM
Note 1
550 through 600
4X #250 AWG
4X 500 MCM
Note 1
Overload Relay
2 through 25
# 14 AWG
# 8 AWG
20 lb. in.
30 through 75
# 10 AWG
# 3 AWG
50 lb. in.
100 through 125
# 6 AWG
250 MCM
275 lb. in., Note 2
150 through 250
# 6 AWG
350 MCM
200 lb. in., Note 2
300
# 8 AWG
500 MCM
375 lb. in., Note 2
Drive output power
Terminal Board
1 through 10
# 4 AWG
# 10 AWG
16 lb.in
15 through 25
# 10 AWG
# 7 AWG
16 lb.in
30 through 40
# 35 AWG
# 2 AWG
40 lb.in
50 through 75
# 50 AWG
1/0
89 lb.in
100
# 95 AWG
4/0
212 lb.in
125
# 120 MCM
250MCM
212 lb.in
150 through 200
2X2/0
2X2/0
Note 1, 2
250 through 350
2X350 MCM
2X350 MCM
Note 1, 2
450 through 600
4X500 MCM
4X500 MCM
Note 1, 2
Continued…
DEH40603 – Page 3 AN 12-1007 Rev 05, 04/04/2012
