Table – 2 (460V)
Device
AF - 600 HP
Rating(s)
Minimum Wire Size
Maximum Wire Size
Required
Torque
Load Reactor (6KFP
Series)
1 through 5
# 22 AWG
# 10 AWG
4.5 lb. in.
7.5 through 15
# 14 AWG
# 6 AWG
16 lb. in.
20 through 30
# 18 AWG
# 4 AWG
16 lb. in.
40 through 75
# 6 AWG
# 1/0
45 (6 - 4AWG),
50 (2-1/0 AWG)
100
# 2 AWG
# 4/0
150 lb. in.
125 through 300
Note 2
Note 2
Note 1
Load Reactor (6KFP*L
Series) - 3% Z
1 through 7.5
# 22 AWG
# 10 AWG
4.5 lb. in.
10 through 25
# 14 AWG
# 6 AWG
16 lb. in.
30 through 75
# 6 AWG
# 1/0
45 (6 - 4AWG),
50 (2-1/0 AWG)
100 through 600
Note 2
Note 2
Note 1
Load Reactor (6KFP*L
Series) - 1% Z
1 through 7.5
# 22 AWG
# 10 AWG
4.5 lb. in.
10 through 15
# 14 AWG
# 6 AWG
16 lb. in.
20
# 22 AWG
# 14 AWG
16 lb. in.
25
# 14 AWG
# 6 AWG
16 lb. in.
30 through 60
# 6 AWG
# 1/0
45 (6 - 4AWG),
50 (2-1/0 AWG)
75 through 600
Note 2
Note 2
Note 1
Control Terminal Board
2 through 300
# 26 AWG
# 10 AWG
Note 1
Note (1): For unmentioned torques, Refer UL508A tables in tab "UL508A" in the same excel file
Note (2): The input and output terminals have Busbars provision for motor connections.
