Table – 3 (575V)
Device
AF - 600 HP Rating(s)
Minimum Wire Size
Maximum Wire Size
Required Torque
NON FUSED
DISCONNECTOR AND
FUSE BLOCK
1 through 10Hp
# 14 AWG
# 4 AWG
Note 1
15 through 40Hp
# 14 AWG
# 4 AWG
Note 1
50 through 60Hp
# 8 AWG
1/0
Note 1
75 through 100Hp
# 8 AWG
1/0
Note 1
125 through 150Hp
# 4 AWG
300 MCM
Note 1
200 through 300Hp
# 2 AWG
600 MCM
Note 1
FUSED DISCONNECTOR
1 through 40
# 10 AWG
# 3 AWG
Note 1
50 through 60
# 14 AWG
# 2/0 AWG
Note 1
75 through 125
# 6 AWG
# 3/0 AWG
Note 1
150 through 300
# 2 AWG
600MCM
Note 1
350 through 650
2 X # 2 AWG
2 X 600MCM
Note 1
Circuit Breaker
1 through 75
# 12 AWG
# 3/0 AWG
Note 1
100 through 200
# 8 AWG
350 MCM
Note 1
250 through 450
2 X 2/0
2 X 500 MCM
Note 1
250 through 450
#8 AWG
600 MCM
Note 1
500 through 650
3X #3/0 AWG
3X 500 MCM
Note 1
Overload Relay
2 through 25
# 14 AWG
# 8 AWG
20 lb. in.
30 through 75
# 10 AWG
# 3 AWG
50 lb. in.
100 through 150
# 6 AWG
250 MCM
275 lb. in. Note 2
Drive output power
Terminal Board
1 through 10
# 4 AWG
# 10 AWG
16 lb.in
15 through 25
# 16 AWG
# 6 AWG
16 lb.in
30 through 50
# 35 AWG
#2 AWG
40 lb.in
60 through 75
# 50 AWG
1/0
89 lb.in
100
# 95 AWG
4/0
212 lb.in
125
150MCM
250MCM
212 lb.in
150 through 200
2x2/0
2x2/0
Note 1, 2
250 through 400
2x350MCM
2x350MCM
Note 1, 2
450 through 650
4x500MCM
4x500MCM
Note 1, 2
Continued…
